Dynamics of Core Taking out at Die Casting

Abstract:

The belonging amplitude and the phase characteristic and the transient characteristic are for K=1 and P=1 identical as for the action quantity. The core puller at pulling cores it is possible to consider as the regulation system with the force of cores pulling F₁ as the inlet quantity and the course of core movement x respectively the speed of core movement v as the outlet quantity. The equation of the regulation system is identical with the equation of regulation system obtained by a gradual integration from the measured course at pulling cores at the die cast. At application of the proportional regulator the amplitude, the phase and the transient characteristic of the action quantity and the control of the regulation circuit constructed on the basis of the transmission state that the circuit is stable a periodic. The amplitude, the phase and the transient characteristic of the regulation circuit defect constructed on the basis of the transmission state that the defect in the regulation circuit lowers relatively quickly.

• Periodical: Applied Mechanics and Materials (Volume 616)
• Pages: 244-251
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.616.244
• Online since: August 2014
• Authors: Juraj Ružbarský*
• Keywords: Core, Die Casting, Dynamic

References

[1] J. Valecký, et al., Casting of metals under pressure, SNTL Praha, (1963).

[2] E. J. Vinarčik, High Integrity Die Casting Processes, John Wiley and Sons, New York, (2003).

[3] E. Ragan, Contribution to the dynamics of the core withdrawal at die casting (Príspevok k dynamike vytiahnutia jadra pri liatí pod tlakom), Slévařenství 9 (1982) 375-377.

[4] E. Ragan, J. Ružbarský, Mechanical properties of the castings at die casting (Mechanické vlastnosti odliatkov pri liatí pod tlakom), Acta Mechanica Slovaca 13 (2007) 36-39.

[5] J. Ružbarský, J. Žarnovský, Device for the treatment of the mold when casting metal under pressure and its dynamics (Zariadenie na ošetrovanie formy pri liatí kovov pod tlakom a jeho dynamika), in: Quality, technology, diagnostics in technical systems: Proceedings (Kvalita, technológie, diagnostika v technických systémoch: Zborník). Nitra: SPU, 2013, 165-169.

[6] Š. Gašpar, J. Paško, H. Beloev, Production technology of aluminium castings by die casting. Ruse: University of Ruse, 2013, 195 p.

[7] M. Kotus, T. Holota, T. Pauliček, M. Petrík, M. Sklenár, Quality and Reliability of Manufacturing Process in Automation of Die-Casting, Advanced Materials Research 801 (2013) 103-107.

DOI: 10.4028/www.scientific.net/amr.801.103

[8] J. Žarnovský, J. Malík, I. Kováč, Influence of holding pressure at aluminum and iron alloys casting under pressure, Vplyv pôsobenia dotlaku pri liatí hliníkových a železných zliatin pod tlakom, Slévárenství 58 (2010) 104-105.

[9] Ľ. Boháčik, J. Žarnovský, Spayed layers on the parts incoming in contact with liquid metal at presure die casting, in: Proc. of 9th Inter. Sci. Symposium Quality and reliability of machines 2004. Nitra: SPU, 2004, pp.126-130.

[10] J. Malík, J. Žarnovský, Die life at pressure die casting, Slévárenství 57/11-12 (2009) 424-425.

[11] J. Ružbarský, Natryskiwanie plazmowe i cieplne metali. Rzeszów: Wyzsza Szkola Inzynieryjno-Ekonomiczna z siedziba, 2013, 120 p.

[12] Š. Gašpár, J. Paško, J. Ružbarský, Die Casting Defects of Castings from Silumin, Applied Mechanics and Materials 510 (2014) 91-96.

DOI: 10.4028/www.scientific.net/amm.510.91

[13] J. Žitňanský, J. Žarnovský, J. Ružbarský, Analysis of Physical Effects in Cutting Machining, Advanced Materials Research 801 (2013) 51-59.

DOI: 10.4028/www.scientific.net/amr.801.51

[14] P. Hrabě, R. Chotěborský, J. Ružbarský, J. Žarnovský, Comparison of high chromium and boride hardfacing, in: Proc. of 4th Inter. Conf. Trends in Agricultural Engineering, Praha, 2010, pp.228-231.

[15] M. Müller, J. Ružbarský, J. Paško, J. Žarnovský, P. Hrabě, The quality of cut surface without cooling, Proc. of 4th Inter. Conf. Trends in Agricultural Engineering, Praha, 2010, pp.459-462.
