Diagnostics of Errors at Component Surface by Vision Recognition in Production Systems

Abstract:

The article deals with the diagnostics of components surface after painting by camera system in real-time. This solution is especially suitable for implementation to automatized production line above the conveyor belt. The faults on the part surface can be detected as scratches, imperfect surface coverage and dirt stuck to the surface. The scratch detection is based on edge detectors, imperfect coverage are checked by histogram comparison and all other errors are detected by counter detectors. The developed software uses open source library OpenCV and is written in C++ language. The software solution is platform independent. Final algorithm is implemented to embedded device based on SoC.

• Periodical: Applied Mechanics and Materials (Volume 616)
• Pages: 227-235
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.616.227
• Online since: August 2014
• Authors: Kamil Židek*, Vladislav Maxim, Radoslav Sadecký
• Keywords: Image Processing, Inspection System, Quality Assurance

References

[1] K. Židek, E. Rigasová, Diagnostics of Products by Vision System, Applied Mechanics and Materials 308 (2013) 33-38.

DOI: 10.4028/www.scientific.net/amm.308.33

[2] Mathworks, Matlab, Computer Vision System Toolbox, [online], available at: <http: /www. mathworks. com/products/computer-vision/description5. html>.

[3] National Instruments, Machine Vision Software, [online] available at: <http: /www. ni. com/vision/software>.

[4] OpenCv Library, [online] available at: <http: /opencv. willowgarage. com/wiki>.

[5] EmguCv Library, [online] available at: <http: /www. emgu. com/wiki/index. php/Main_Page>.

[6] AForge. Net Library, [online] available at: <http: /www. aforgenet. com/framework>.

[7] T. Leung, J. Malik, Representing and Recognizing the Visual Appearance of Materials using Three-dimensional Textons, International Journal of Computer Vision 43 (2001) 29–44.

[8] Q. Zaidi, Visual inferences of material changes: color as clue and distraction, Wiley Interdiscip Rev Cogn Sci., 2011, p.686–700.

DOI: 10.1002/wcs.148

[9] C. Liu, L. Sharan, E.H. Adelson, R. Rosenholtz, Exploring Features in a Bayesian Framework for Material Recognition, in: Proc. of IEEE Conference on Computer Vision and Pattern Recognition, (2010).

DOI: 10.1109/cvpr.2010.5540207

[10] Lead-based paint: Testing methods. US Department of Agriculture Forest Service, Technology & Development Program, 1996, available at: <www. fs. fed. us/eng/pubs/ htmlpubs/htm96712353/>.

[11] J. Canny, A computational approach to edge detection, IEEE Trans. Pattern Analysis and Machine Intelligence 8 (1986) 679-714.

DOI: 10.1109/tpami.1986.4767851

[12] R. O. Duda, P. E. Hart, Use of the Hough Transformation to Detect Lines and Curves in Pictures, Comm. ACM 15 (1972) 11–15.

DOI: 10.1145/361237.361242

[13] F. Duchoň, K. Marian, L. Jurišica, Reactive Navigation of Mobile Robot with Visual System, Acta Mechanica Slovaca 13/2-A (2009) 47-52.

[14] M. Balara, The parametric invariants control system, in: 20th DIDMATTECH, Olomouc: Votobia, 2007, pp.109-114.

[15] J. Boržíková, J. Piteľ, M. Tóthová, M., B. Šulc, Dynamic simulation model of PAM based antagonistic actuator, in: Proc. of 12th Int. Carpatian Control Conf. ICCC 2011: 25-28 May 2011, Velké Karlovice, Czech Republic, IEEE, 2011, pp.32-35.

DOI: 10.1109/carpathiancc.2011.5945809

[16] A. Hošovský, M. Havran, Dynamic Modeling of One Degree of Freedom Pneumatic Muscle-based Actuator for Industrial Applications, Technical Gazette 19 (2012) 673-681.

[17] K. Židek, J. Šeminský, M. Dovica, A. Hošovský, Wireless mobile device with integrated image processing, in: Proc. of 8th Technical Conf. ARaP, Praha, 2012, pp.37-42.

[18] J. Svetlík, P. Demeč, Virtual machining and its experimental verification, Acta Mechanica Slovaca 13/4 (2009) 68-73.

DOI: 10.2478/v10147-010-0039-8
