Design, Fabrication and Evaluation of a Novel Electro Thermal Micro-Gripper for Handling of Head Gimbal Assembly

Abstract:

A development of a novel electro thermal micro-gripper for handling of Head Gimbal Assembly (HGA) is an ultimate goal of this study. The scope of this study covers a design, fabrication and performance evaluation of the electro thermal micro-gripper. ANSYS software was used to examine the magnitude of tip displacement, exerting force and induced stress to investigate the mechanism’s viability for handling of HGA. Electroplating of nickel was employed to construct the micro-gripper’s mechanisms with three different sizes, and their displacement and exerting force were then examined. From the experiments, each mechanism deflected between 100 to 220 μm while the exerting force was over 200 mN at 25 ^oC above room temperature. Therefore, the results suggested that the new electro thermal micro-grippers are viable for the HGA handling application.

• Periodical: Applied Mechanics and Materials (Volume 619)
• Pages: 156-161
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.619.156
• Online since: August 2014
• Authors: Alongkorn Pimpin*, Thanapon Anuchitworawong, Nirun Jandabao, Samach Saengchote, Chanat Ratanasumawong, Werayut Srituravanich
• Keywords: Electro Thermal Actuator, Electroplating, End-Effecter, Head Gimbal Assembly, Micro Fabrication, Micro-Gripper

References

[1] R. Wood: J. Magnetism Magnetic Materials Vol. 321 (2009), p.555.

[2] A. Pimpin, K. Prapaipittayakhun, W. Srituravanich, T. Lertsirarungsun and V. Lertapiruk: Proc. 4th Int. Data Storage Technology Conference. Thailand, 9-10 January (2012).

[3] D.J. Bell, T.J. Lu, N.A. Fleck and S.M. Spearing: J. Micromech. Microeng. Vol. 15 (2005), p.153.

[4] D.H. Kim, Y.C. Park and S. Park: Sensors Actuators A Vol. 159 (2010), p.79.

[5] S. Pal and H. Xie: Sensors Actuators A Vol. 170 (2011), p.156.

[6] U. Izhar, A.B. Izhar and S. Tatic-Lucic: Sensors Actuators A Vol. 167 (2011), p.152.

DOI: 10.1016/j.sna.2011.04.003

[7] B.S. Kim, J.S. Park, B.H. Kang and C. Moon: Robo. and Comp-Integ. Manu. Vol. 28 (2012), p.50.

[8] S. Krishnan and L. Saggere: Sensors Actuators A Vol. 176 (2012), p.110.

[9] I.K. Lin, X. Zhang and Y. Zhang: Sensors Actuators A Vol. 168 (2011), p.1.

[10] S.E. Zhu, R. Shabani, J. Rho, Y. Kim, B.H. Hong, J.H. Ahn and H.J. Cho: NANO Letters Vol. 11 (2011), p.977.

[11] A. Pimpin, E. Wongweerayoot and W. Srituravanich: Applied Mech. Mat. Vol. 225 (2012), p.367.

[12] A. Pimpin, K. Intarasuksanti, E. Wongweerayoot and W. Srituravanich: Applied Mech. Mat. Vol. 225 (2012), p.350.

DOI: 10.4028/www.scientific.net/amm.225.350
