2x2 Rectangular-Slot Microstrip Array Antenna for WLAN Applications

Abstract:

This paper presents the design of a 2 x 2 microstrip array antenna suitable for wireless applications. Its basic structure is a microstrip comprising of three layers of which a 2x2 patches are etched on the top layer to act as the radiating element. The middle layer is a metal ground with rectangular slots and the bottom layer consists of a microstrip feedline. A larger bandwidth and the desired resonant frequency are achieved because of a reduction in the quality factor (Q) of the patch resonator, which is due to less energy being stored beneath the patch due to the rectangular arrangement of the slots. The characterization results of return loss, gain, and radiation pattern are presented consecutively. From the results, the simulated impedance bandwidth defined for S11<-10dB reaches 1850MHz (4.69-6.54GHz) representing 16.47%.

• Periodical: Applied Mechanics and Materials (Volume 619)
• Pages: 162-165
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.619.162
• Online since: August 2014
• Authors: Obeng Kwakye Kingsford Sarkodie*
• Keywords: Array Antenna, Patch, Slot, Wireless

References

[1] L. G. Maloratsky, Reviewing the basics of microstrip lines, Microwave & RF. pp.79-88, March (2000).

[2] Mohanna, S, Ghassemi, N., Wideband aperture coupled microstrip array antennas for radar applications, Microwave Radar and Wireless Communications(MIKON), 2010 18th International Conference on Radar and Wireless Communications. pp.1-2, June (2010).

DOI: 10.1109/mikon.2002.1017960

[3] K.L. Lau, K.M. Luk and K.F. Lee, Wideband U-slot microstrip patch antenna array, IEE Proc. -Microw. Antennas Propag., Vol. 148, No. 1. pp.41-44 February (2001).

DOI: 10.1049/ip-map:20010220

[4] Chang won Jung and Franco De Flaviis, A Dual-Band Antenna for WLAN Applications by Double Rectangular Patch with 4-Bridges, Antennas and Propagation Society International Symposium, 2004. IEEE, vol. 4, p.4280 – 4283, June (2004).

DOI: 10.1109/aps.2004.1330297

[5] S. Egashira, E. Nishiyama, A. Sakitani, Stacked microstrip antenna with wide band and high gain, IEEE Antennas and Propagation Society International Symposium, vol. 3, pp.1132-1135, May (1990).

DOI: 10.1109/aps.1992.221495

[6] Pues H.F. and Van De Capelle A.R. Impedance matching of microstrip resonator antenna, Proceedings of the North American Radio Science Meeting, Quebec, p.189, (1980).

[7] Swapnil S. Thorat, R.C. Jaiswal, Dr. Rajkumar, S.D. Lokhande, Efficient technique for Bandwidth Improvement of Microstrip Patch Antenna, International Journal of Computer Networks and Wireless Communications(IJCNWC), Vol. 2, No6, pp.728-732, Dec (2012).

[8] Amir Reza Dastkhosh and Hamid Raza Dalili Oskouei, A wideband High-Gain Dual-Polarized Slot Array Patch Antenna for WiMAX Applications in 5. 8GHz, , International Journal of Antennas and Propagation, vol. 2012, Article ID 595290, 6pages (2012).

DOI: 10.1155/2012/595290

[9] Chao Sun; Jiu-sheng Li, A novel planar microstrip array antenna for WLAN applications, Microwave, Antenna, Propagation, and EMC Technologies for Wireless Communications (MAPE), pp.16-17, Nov (2011).

DOI: 10.1109/mape.2011.6156300
