Kinematics Model of the 6-DOF Underwater Manipulator and Control System Design Based on PLC Technology

Abstract:

The paper introduces kinematics analysis for a kind of 6 degrees of freedom underwater manipulator. Firstly, kinematics model was established based on D-H principle; The solving process of kinematics direct solution and inverse solution of manipulator was presented. Secondly, Numerical simulation is performed based on ADAMS software, every joint speed and acceleration curve is obtained. The working principals and control requirement of underwater manipulator are illustrated; Based on kinematics modeling, the control system of manipulator was designed based on PLC and carried out the control the function of the manipulator.

• Periodical: Applied Mechanics and Materials (Volume 620)
• Pages: 343-346
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.620.343
• Online since: August 2014
• Authors: Tao Yao*, Zong Yu Chang
• Keywords: Control System, Kinematics Model, PLC Technology, Underwater Manipulator

References

[1] Zhang Xichao, Underwater Robot-Manipulator System Dynamics Analysis and Control [D], Master dissertation of Ocean University of China(2011).

[2] Kato N., Lane D.M. Coordinated control of multiple manipulators in underwater robots, In Proc. Of 1996 IEEE Int. Conf. on Robotics and Automation, (1996)2505-2510.

[3] John Craig, Introduction to Robotics, Translated by Su Zhongfei, Guo Zizheng etc., Xi An: Northwestern Polytechnic University Press(1987).

[4] Hu Mingmao, Open-frame Underwater Robot System Identification and Control Technology Research [D], Harbin: Harbin Engineering University(2007).
