Distortion Correction of Image in Integral Stereolithography System

Abstract:

There is geometric distortion of image in integral Stereolithography (SL) system, and the geometric distortion will influence the building accuracy of the SL system. To improve the building accuracy of the SL system, researches of distortion correction of image in the SL system are carried out. The distortion model of binary cubic polynomial interpolation is established with least-square method. The gray scale rebuilding is implemented with space-variable linear interpolation by using VC++6.0. The experimental results indicate that the geometric distortion of the image in integral SL system has been eliminated remarkably, and the radial RMS error is 0.96 pixels. The research lays a foundation for improving building accuracy of the integral SL System.

• Periodical: Applied Mechanics and Materials (Volumes 63-64)
• Pages: 197-200
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.63-64.197
• Online since: June 2011
• Authors: Guang Shen Xu, Gen Yang
• Keywords: Distortion Correction of Image, Gray Scale Rebuilding, Integral Stereolithography

References

[1] B. Arnaud, B. Paul and V. Christian: Rapid Prototyping Journal, Vol. 6 (2002) No. 4, p.259.

[2] G.S. Xu, X.M. Ma, S. Luo and R.H. Qiu: Chinese Journal of Lasers. Vol. 37 (2010), p.1892(in Chinese).

[3] Y.B. Wu, G.X. Song: Journal of Image and Graphics. Vol. 10 (2005), p.269 (in Chinese).

[4] W. Faig: Photogrammetic engineering& Remote Sensing. Vol. 41 (1975), p.1479.

[5] H.Z. Cui,K. Yuan Q.B. Zhou and Z.X. Pan: Journal of Applied Optics. Vol. 27 (2006), p.183 (in Chinese).

[6] J.G. Li: Journal of Image and Graphics. Vol. 33 (2004), p.732 (in Chinese).

[7] G. Ramponi: IEEE Transaction on Image Processing. Vol. 8 (1999), p.629.

[8] S.Z. Liao, P.H. Gao, Y. Su,D.P. Wang: Journal of Image and Graphics. Vol. 5 (2000), p.593 (in Chinese).
