The CFD Modeling of Probe-Drogue Aerial Refueling Equipment for UAV

Abstract:

To research the automatic alignment problem in autonomous aerial refueling docking phase for UAV, by simulating the aerodynamic parameters of aerial refueling equipment the Probe-Drogue aerial refueling model was built. The three-dimensional graphics of the refueling hose intercepted segment, drogue and stable umbrella were drawn using CATIA, which were imported into GAMBIT for generating three-dimensional flow field grids. Then, the refueling hose intercepted segment model was calculated after setting the solution parameters in FLUENT for different flow angles and Mach number. At the same time, monitoring the convergence of the residuals, a group of stable aerodynamic parameters were obtained, which provided needed parameters for aerial refueling modeling.

You might also be interested in these eBooks

Advanced Research on Mechanical Engineering, Industry and Manufacturing Engineering

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 63-64)

Pages:

569-572

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.63-64.569

Citation:

Cite this paper

Online since:

June 2011

Authors:

Dong Li Yuan, Qing Biao Xi, Wen Chao Li, Xiao Jun Xing

Keywords:

Aerial Refueling, Aerodynamic Parameter, Computational Fluid Dynamics (CFD), Three-Dimensional Grid, Unmanned Aerial Vehicle (UAV)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Xinmin Dong, Yuejian Xu, Bo Chen. Progress and Challenges in Automatic Aerial Refueling[J]. Journal of Air Force Engineering University(Natural Science Edition), 2008. 12(6): 1-5.

Google Scholar

[2] Jennifer L. Hansen, James E. Murray, Norma V. Campos. The NASA Dryden AAR Project: A Flight Test Approach to an Aerial Refueling System [C]. AIAA Atmospheric Flight Mechanics Conference and Exhibit, 16-19 August 2004, Providence, Rhode Island: AIAA 2004-4939.

DOI: 10.2514/6.2004-4939

Google Scholar

[3] Yunbo Zhao. CATIA V5 foundation tutorial [M]. Beijing: People's Posts and Telecommunications Press, 2007. 3.

Google Scholar

[4] Gambit 2. 2 Modeling Guide. Fluent Inc.

Google Scholar

[5] Zhanzhong Han, Jing Wang, Xiaoping Lan FLUENT - Examples and applications of fluid engineering simulation (second edition) [M]. Beijing: Beijing Institute of Technology Press, 2010. 4.

Google Scholar

[6] Fluent 6. 2 User's Guide. Fluent Inc.

Google Scholar
