Three Dimensional Seismic Response Analysis of Complicated Metro Station with Shallow Depth

Abstract:

Focusing on a complicated metro station with shallow depth, its three-dimensional calculation model was established, which includes not only the main station structure, but also includes the subsidiary structure such as the entrances and detailed structures such as the holes in the floor. The Davidenkov model was employed to simulate the nonlinear characteristics of the soil. The three-dimensional nonlinear seismic responses were analyzed. it can be shown from the calculation that: (1) the metro station structure can satisfy the demand under given seismic motion; (2) it is more important for structural concept design and structural measures design than the strength and deformation design for complicated underground structures.

• Periodical: Applied Mechanics and Materials (Volumes 638-640)
• Pages: 1905-1910
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.638-640.1905
• Online since: September 2014
• Authors: Hong Lin*, Xin Pan
• Keywords: Metro Station, Nonlinear Characteristic, Seismic Response, Shallow Depth

References

[1] Akira, T. A study on seismic analysis methods in the cross section of underground structures using static finite element method[J]. Structural Engineering & Earthquake Engineering，2005，122(1)：41-53.

DOI: 10.2208/jsceseee.22.41s

[2] Samata S, Ohuchi H and Matsuda T. A study of the damage of subway structures during the 1995 Hanshin-Awaji earthquake [J]. Cement and Concrete Composites, 1997, 19 (3) : 223-239.

DOI: 10.1016/s0958-9465(97)00018-8

[3] Parra M., Gustavo J., Bobet A. R., and Julio A. Evaluation of soil-structure interaction and structural collapse in Daikai subway station during Kobe earthquake [J]. ACI Structural Journal, 2006, 103 (1) : 113-122.

DOI: 10.14359/15092

[4] ZHUANG Hai-yang, LONG Hui and CHEN Guo-xing. Analysis of the nonlinear earthquake responses of a large complicated subway underground station [J]. Journal of Earthquake Engineering and Engineering Vibration, 2013, 33(2): 192-199. (in Chinese).

[5] LOU Meng-lin, PAN Dan-guang and FAN Li-chu. Effect of vertical artificial boundary on seismic response of soil layer [J]. Journal of Tongji University, 2003, 31(7): 757-761. (in Chinese).

[6] CHEN Yue-qing. Experimental study on structure - soil interaction system by shaking table model test [D]. Shanghai: Tongji Univesity, 2001. (in Chinese).

[7] Itasca Consulting Group. Fast lagrangian analysis of continua in 3 dimensions [R]. Minneapolis: Itasca Consulting Group, Inc., (2002).
