The New Method of Connecting Projection of Structural Planes Exposed Points into a Line

Abstract:

Structural planes in rock mass play a regulatory role in strength, deformation and fracture. It is the primary task to find out spatial distribution of controlling structural planes. The new method of connecting projection of structural planes exposed points into a line is realized by the certain distance from exposed points to the plane. And the plane is determined by its occurrence. Then select the suitable data and project to the ground surface using trigonometric function conversion. Finally connect these projection points into a line. Computation process can be simplified through MATLAB. This new method is applied to draw the exposed trace line of III-class structure in the left dam abutment adits of Yebatan hydroelectric power station in Jinsha river. The results are accurate, which means this method is feasible.

• Periodical: Applied Mechanics and Materials (Volumes 638-640)
• Pages: 710-715
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.638-640.710
• Online since: September 2014
• Authors: Qian Zhang*, Zhi Yuan Wang, Jun Yang, Xin Liao
• Keywords: Connecting Projection of Exposed Points, MATLAB, Rock Mass Structure, Yebatan Hydroelectric Power Station

References

[1] Chun'an Tang. The catastrophe in the process of rock failure. Coal Industry Press, Beijing, China (1993), pp.31-41.

[2] Zhende Gu. Foundation of rock mass engineering geological mechanics. Science Press, Beijing, China (1979).

[3] Guangzhong Sun. Rock mass structure mechanics. Science Press, Beijing, China (1988).

[4] Guangzhong Sun. On the theory of structure-controlled rock mass. Journal of Engineering Geology，1993, (01): 14-18(in Chinese).

[5] Huiming Tang. Foundation of engineering geology. Chemistry Industry Press, Beijing, China (2009).

[6] Denghua Zhong, Mingchao Li, Jianmin Ynag. 3D visual construction of complex engineering rock mass structure and its application. Chinese Journal of Rock Mechanics and Engineering， 2005, (04): 575-580 (in Chinese).

[7] Yanzhang Liu, ianlong Sheng, Xiurun Ge, et al. Evaluation of rock mass quality based on fractal dimension of rock mass discontinuity distribution. Rock and soil Mechanics, 2007, (05): 971-975(in Chinese).

[8] Qiangong Cheng, Houtian Hu, Jianbing Peng, et al. Visco-elastic plastic finite element simulation of progressive failure of high-steep rock slope. Journal of Engineering Geology，2000, (01): 25-30(in Chinese).

[9] Genlan Yang, Runqiu Huang. Numerical long-term stability of dam abutment resistance body for a hydropower station in Southwest China. Journal of Engineering Geology, 2000, (01): 25-30 (in Chinese).
