A Low-Impact Deployment Hinge Based on a Novel Intermittent Mechanism

Abstract:

A novel intermittent mechanism and low-impact deployment hinge based on intermittent mechanism are presented in this paper. This application is contemplated to lower the impact dramatically at the end of hinge deployment. The overall deployment process is described and the maximum impact force and angular velocity are derived. The effect of the intermittent motion mechanism on free spring deployable hinges is evaluated by indexes of maximum angular velocity and impact force. Cases are simulated to verify the mechanism design, and results show that the maximum angular velocity and impact force can be decreased by more than 90%.

You might also be interested in these eBooks

Engineering Providing of Industrial Development

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 643)

Pages:

302-309

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.643.302

Citation:

Cite this paper

Online since:

September 2014

Authors:

Hong Wei Guo*, Zhong Jie Li, Zong Quan Deng, Chuang Shi, Rong Qiang Liu

Keywords:

Impact, Intermittent Mechanism, Low-Impact Hinge Mechanism, Simulation

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Zhang, Zh. J. et al, Research on Modeling of Latch-up Impact Loads Analysis for Solar Arrays, The national structural vibration and dynamics conference, 281-289, (2011).

Google Scholar

[2] Zhang, Zh. J. et al, Study on Latch-up Impact Loads During Solar Wing Deployment, SPACECRAFT ENGINEERING, 21(1): 31-36, (2012).

Google Scholar

[3] Chen, T. Zh. et al, Method of Modifying Maximum Impact Load on Solar Array Deployment and Locking Process, SPACECRAFT ENGINEERING, 20(6): 55-62, (2011).

Google Scholar

[4] Liang, X.G. et al, Selecting method of damper parameters for solar array of satellite, JOURNAL OF HARBIN INSTITUTE OF TECHNOLOGY, 43(7): 71-75, (2011).

Google Scholar

[5] Xiao, Y.T. et al, Study on the Viscous Damper to Reduce the Wallop of the Deployment Solar Array, System Simulation Technology & Application Conference, Vol. 10: 644-647, (2008).

Google Scholar

[6] Liang, X, G. et al, Study on Influence of Damper on Locking Wallop of Deployable Solar Array of Satellite, Noise and Vibration Control, 01: 127-130, (2010).

Google Scholar

[7] WANG, X. et al, Dynamics Simulation Analysis of Solar Array Ground Deployment and Locking, SPACECRAFT ENGINEERING, 20(3): 86-92, (2011).

Google Scholar

[8] Liu, D. Sh. et al, Dynamics and Inverse Design of Impact Machines, chapter 3, 44-45, Science Press (2007).

Google Scholar
