The Design and Simulation of Missile Internal and External Loops with Dual PID Control

Abstract:

A class of height double PID controller based on posture stability is designed in this paper aim at simplified dynamics model of missile pitch channel linearization and simplified model of missile height kinematics link. The implement process of using matlab software simulink toolbox is introduced in detail. Secondly, The transfer function calculating algorithm which solves nonlinear link in simulink using matlab language linmod function is proposed in this paper aim at nonlinear of height kinematics link. Finally, the bode diagram of whole system is obtained and the stability margin of system is analyzed by computer simulation.

• Periodical: Applied Mechanics and Materials (Volumes 644-650)
• Pages: 146-149
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.644-650.146
• Online since: September 2014
• Authors: Jin Huang Wu*, Jun Wei Lei, Jian Hong Shi, Di Liu
• Keywords: Missile, Pitch Channel, Posture, Stability Margin, Transfer Function

References

[1] Han Y H, Xu B. Variable structure guidance law for attacking surface maneuver targets[J]. Journal of Systems Engineering and Electronics, 2008, 19(2) : 337－341.

DOI: 10.1016/s1004-4132(08)60088-2

[2] Elmali H. Olgac N. Implementation of sliding mode control with perturbation estimation ( SMCPE) [J]. IEEE Transactions on Control Systems Technology, 1996, 4( 1) : 79－85.

DOI: 10.1109/87.481770

[3] Li Y M. Xu Q S. Adaptive sliding mode control with perturbation estimation and PID sliding surface for motion tracking of a piezodriven micromanipulator[J]. IEEE Transactions on Control Systems Technology, 2010, 18( 4) : 798－810.

DOI: 10.1109/tcst.2009.2028878

[4] Levant A. Homogeneity approach to high-order sliding mode design[J]. Automatica, 2005, 41( 4) : 823－830.

DOI: 10.1016/j.automatica.2004.11.029

[5] Schmidt D K and Velapoldi J R. Flight dynamics and feedback guidance issues for hypersonic Airbreathing vehicles[A]. In: AIAA Guidance, Navigation, and Control Conference and Exhibit [C]. Portland, OR, AIAA 99-4122.

DOI: 10.2514/6.1999-4122

[6] Parra-Vega V, Arimoto S, Liu Y H. Dynamic sliding PID control for tracking of robot manipulators: Theory and experiments[J]. IEEE Transactions on Robotics and Automation, 2003, 19( 6) : 967－976.

DOI: 10.1109/tra.2003.819600

[7] Fidan B, Mirmirani M and Ioannou P A. Flight dynamics and control of air-breathing hypersonic vehicles: review and new directions[A]. In: 12AIAA International Space Planes and Hypersonic Systems and Technologies Conference and Exhibit[C]. Norfolk, VA, AIAA 2003-7081.

DOI: 10.2514/6.2003-7081

[8] Chang K R. Hang J C. Min J T. Optimal guidance laws with terminal impact angle constraint[J]. Journal of Guidance，Control, and Dynamics, 2005, 28(4): 724－732.

DOI: 10.2514/1.8392
