Simulation of Hydraulic Characteristic of Injecting Cable into Coiled Tubing

Abstract:

In order to control and monitor downhole equipment, it is needed to inject cable into coiled tubing. Being directly against the drawback of the traditional injecting method, a new method of adding pressurized water has been put forward. By using Workbench software, this paper researched the regular pattern that water flow’s pressureaffects cable in coiled tubing after it has various deformations in both entrance and main part of coiled tubing, taking 25mm diameter coiled tubing with 3mm diameter cable as an example. It also simulated the effects of water flow toward cable in coiled tubing as well as how the different diverging distances of entrance for injection affects the speed of cable during injection, taking 50.8mm diameter coiled tubing with 5.6 mm diameter cable as an example. It determined the optimal position of cable entrance and provided the theoretic foundation for the possibility and practical manipulation of the new method for injecting cable into coiled tubing.

• Periodical: Applied Mechanics and Materials (Volumes 644-650)
• Pages: 1682-1688
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.644-650.1682
• Online since: September 2014
• Authors: Yi Ding*, Feng Niu, Shi Min Zhang, Jin Jun Zhang
• Keywords: Cable Injection, Coiled Tubing, Downhole Monitoring, Hydraulic Simulation

References

[1] M. Taggart, N. Murray, T. Sturgeon, Baker Hughes. New real-time data: Communication system enhances coiled tubing operations[C]. 10th Offshore Mediterranean Conference and Exhibition, Italy, March 23-25, 2011: 1-21.

DOI: 10.2118/134389-ms

[2] E.P. Howell, L.J. Smith, C.G. Blount. Coiled-Tubing Logging System.

[3] E. Quintero, A. Quezada, I. Romero. Technical-Economic Evaluation of Downhole Electric Heater Cable Application in Orinoco Oil Belt: Successful Case[C]. SPE Latin American and Caribbean Petroleum Engineering Conference, 21-23 May 2014: 1-8.

DOI: 10.2118/169351-ms

[4] K.R. Newman, N.A. Haver, L.R. Stone, L.C. and D. Tong. Development of a Coiled Tubing Cable Installation System[C]. SPE Annual Technical Conference &Exhibition, 22-25 October, 1995: 389-395.

DOI: 10.2118/30679-ms

[5] Kenneth R. Newman; Lyndon R. Stone; David C. Tong. Method and Apparatus for the Injection of Cable into Coiled Tubing[P]. US: 5503370. (1996).

[6] W. Griffioen; Gerard Plumettaz; Arie Van Wingerden. Method for inserting a cable-like element into a tube coiled in or on a holder[P]. US: 5950298. (1999).

[7] Andre J. Naumann. System and Methods for Injecting or Retrieving Tubewire into or out of Coiled Tubing[P]. US: 7845419B2. (2010).

[8] Willem Griffioen, Patrice Blanchetm Gerard Plumettaz. NEW TECHNIQUE TO INSTALL POWER CABLES INTO DUCTS[J]. 8th International Conference on Insulated Power Cables, 19-23 June, (2011).
