Varying Rotation Speed Bearing Fault Features and Extraction Method Based on Wavelet Packet

Abstract:

When bearing rotates, it comes with elastic hydrodynamic lubrication effect. Interaction between the effect and the bearing vibration leads to the change of lubricant film thickness, thus, contact stiffness of contact pair changes along with the rotation speed of the bearing, and then the resonance frequencies of the bearing system changes according to the rotation speed. In addition, the impact signal of varying speed bearing damage point no longer has the periodic characteristics. Based on the analysis of the bearing failure mechanism, this paper proposed a varying speed bearing vibration signal fault model, and also utilizes wavelet packet to extract the bearing fault signal by means of a variable speed rolling bearing vibration experiment table.

• Periodical: Applied Mechanics and Materials (Volumes 644-650)
• Pages: 286-289
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.644-650.286
• Online since: September 2014
• Authors: Bin Wu*, Shan Ping Yu, Yue Gang Luo, Chang Jian Feng
• Keywords: Bearing, Characteristic Extraction, Varying Rotation Speed, Wavelet Packet

References

[1] Y Kim Paul and Cowe LR.G. A review of rolling element bearing health monitoring. Proceeding of Machinery Vibration Monitoring and Analysis Meeting [C]. April 1983: 19-21.

[2] Girondin Victor, Pekpe Komi Midzodzi, Morel Herve, et al. Bearings fault detection in helicopters using frequency readjustment and cyclostationary analysis. Mechanical Systems and Signal Processing. 2013(38) 2: 499-514.

DOI: 10.1016/j.ymssp.2013.03.015

[3] Zhang Chao, Chen Jian-Jun1, Xu Ya-Lan1. A bearing fault diagnosis method based on EMD and difference spectrum theory of singular value. Journal of Vibration Engineering. 2011(24)5: 539-545.

[4] Sunnersjo C.S. Rolling bearing vibration一the effects of geometrical imperfaction and wear[J]. Journal of sound and vibration. 1985(98)4: 445-474.

DOI: 10.1016/0022-460x(85)90256-1

[5] Zhao Lianchun, Ma Jiajun, Cao Zhifei. The influence of design and application parameters on the ball bearing vibration characteristics[J]. Bearing. 2006 (1): 4-8.

[6] G. Meltzera, Nguyen Phong Dienb. Fault diagnosis in gears operating under non-stationary rotational speed using polar wavelet amplitude maps[J]. Mechanical Systems and Signal Processing, 2004, (18): 985–992.

DOI: 10.1016/j.ymssp.2004.01.009

[7] Xianfeng Fan, Ming J. Zuo. Gearbox fault detection using Hilbert and wavelet packet transform [J]. Mechanical Systems and Signal Processing. 2006(20): 966–982.

DOI: 10.1016/j.ymssp.2005.08.032

[8] Rubibi R. and Meneghetti U. Application of the envelope and wavelet transform analyses for the diagnosis of incipient faults in ball bearings[J]. Mechanical Systems and Signal Processing, 2001, 15(2), 287-302.

DOI: 10.1006/mssp.2000.1330
