The Electromagnetic Parameters' Impact of λ/4 Type Dielectric Absorber on Absorbing Properties

Abstract:

This paper studies electromagnetic parameters' impact of λ/4 type dielectric absorber on absorbing properties. Calculation shows that the maximum absorption amount is corresponding to specific values of K and R when absorber's permittivity is stable, when the thickness of material is determined and the real part permittivity is increased, the absorption peaks move to lower frequency and reduce the distance between adjacent peaks, while the imaginary part of permittivity and resistance of membrane resistance only affect absorption peaks' amount but have no effect on the peaks' position. Accordingly, it is reasonable to adjust the material's electromagnetic parameters according to the above rule when the high-performance λ/4 dielectric-type absorber is prepared.

• Periodical: Applied Mechanics and Materials (Volumes 644-650)
• Pages: 3593-3596
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.644-650.3593
• Online since: September 2014
• Authors: Hui Chao Zhao, Wan Jun Hao*, Ying Ying Yi, Yi Feng Dong, Xin Dan Yu
• Keywords: Dielectric Absorber, Electromagnetic Parameter, Peak Position Forward

References

[1] SM. Xue, WLAN and implementation technique Journal of Northwest University for Nationalities(Natural Science), Vol. 24 No. 3（2003） P: 50-56.

[2] O. Hashimoto《Technologies and Applications of Wave Absorber》ＣＭＣ , 2004. P：10-30.

[3] W.J. Hao, Measure and countermeasures. of Electromagnetic radiation . Miyagi prefecture ITC research report 2001 , 3 : P3-10.

[4] S.H. Liu, J.M. Liu and X.L. Dong. electromagnetic wave shielding and absorbing material, chemical industry press, Beijing. 2007. P: 50-80.

[5] Adam J. Douglas, Davis Lionel E, etc, Ferrite device and materials, IEEE Trans. on Microwave Theory and Technology . Vol. 50. No. 3(2002), P: 721-724.

[6] S.H. Wang, F. Wen and W.J. Hao. 2006. Electromagnetism Pollution and Protection Materials for Electromagnetic Radiation, Environmental Science and Technology, 12(29): P: 96—98.

[7] Wu Fan, Hao Wan jun etc. The double-layer matching design of broad-band foam cement absorbing panel for electromagnetic pollution control Applied Mechanics and Materials Vols. 2013: 924-928.

DOI: 10.4028/www.scientific.net/amm.401-403.924

[8] J.J. Chen W.J. Hao* Y.F. Zhang X.L. Zhao Stretching Design For Plasterboard Of λ/4 Type EMW-Absorber International Conference on Heterogeneous Material Mechanics (ICHMM), JUN 03-08, P：533-536.

[9] LV Shuzhen, CHEN Ning, WANG Haibin, HUO Jichuan. The Interference in Transmission Line Theory and Its Application in Cement-Based Material [A]. Journal of Changchun University of Science and Technology (Natural Science Edition), 2010, 33(2): 103-106.

[10] K. Ansayi etc, Cement Absorber 「Industrial materials」vol. 48. No. 12(2000): 56-60.
