Simulation and Mathematical Modeling on Bending of Pipe Subjected to Internal Pressure

Abstract:

This Paper Aims from the Simulation Tests to Highlight the Influence of the Diameter and Material Quality, Reflected by the Flow Limit of the Pipe and the Quality and Technological Parameters at the Bending under Pressure of the Pipes. from Literature, those Quality Parameters which Characterize a Correct Bending are: the Ovality of the Transversal Section, the Variation of the Wall Thickness or Eccentricity, the Lack of Whetstones, the Resistance in Function of the Bent Pipe. Pipe Material Characteristics Influence the Quality Parameters of the under Pressure Modeling Process, in the Sense that at the Materials with Small Flow Limit, Ovality or Variation of the Wall Thickness are Small. at Pipes under Pressure Modeling, Ovalities and Variation of the Wall Thickness are in Permissible Limits Valid Recommended for Domains without Special Precision Restrictions.

• Periodical: Applied Mechanics and Materials (Volume 657)
• Pages: 639-643
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.657.639
• Online since: October 2014
• Authors: Ionel Olaru*, Dragoş Iulian Nedelcu
• Keywords: Bending, Material, Parameter, Pipes, Pressure, Tensions

References

[1] S. M. Rahmana, T. Hassana, C. Edmundo, Evaluation of cyclic plasticity models in ratcheting simulation of straight pipes under cyclic bending and steady internal pressure, International Journal of Plasticity. 24, Issue 10 (2008) 1756–1791.

DOI: 10.1016/j.ijplas.2008.02.010

[2] G-Y Zhua, M. A. Hensona, L. Megan, Dynamic bending and linear model predictive control of gas pipeline networks, Journal of Process Control. 11 (2001) 129-148.

DOI: 10.1016/s0959-1524(00)00044-5

[3] H.F. Abdalla, Shakedown boundary determination of a 90° back-to-back pipe bend subjected to steady internal pressures and cyclic in-plane bending moments, International Journal of Pressure Vessels and Piping. 116 (2014) 1-9.

DOI: 10.1016/j.ijpvp.2014.01.001

[4] D.D. Dragoi, The study regarding the behavior of loaded pipes, Recent Advances in Mathematical Methods, Intelligent Systems and Materials. 9 (2013) 93-96.

[5] T. M. Christo, A.R. Veerappan, S. Shanmugam, Comparison of plastic limit and collapse loads in pipe bends with shape imperfections under in-plane bending and an internal pressure, International Journal of Pressure Vessels and Piping. 99–100 (2012).

DOI: 10.1016/j.ijpvp.2012.07.013

[6] P.A. Velmisov, Y.V. Pokladova, An investigation of mathematical models of a pipeline – pressure sensor mechanical system, ROMAI J. 2 (2006) 219-225.

[7] C.H. Lee, K.H. Chang, Study on the residual stresses in girth-welded steel pipes and their evolution under internal pressure, Marine Structures. 34 (2013) 117-134.

DOI: 10.1016/j.marstruc.2013.09.001

[8] Information on SolidWorks Flow Simulation, www. solidworks. com, accessed: 15. 03. (2014).
