Parameter Identification and Modeling of a Pneumatic Proportional Valve with Applicability in Control Design of Servo-Pneumatic Systems

Abstract:

The key element in a servo-pneumatic actuation system is the control valve. This paper presents a method for parameter identification and modeling the flow characteristic of a FESTO MPYE-5-1/8-HF-101B proportional valve. An experimental setup and a procedure for parameter identification is presented in the paper. Simulation and experimental results are in agreement and the model of the valve could be used in high-accuracy positioning control design of pneumatic servo-systems.

• Periodical: Applied Mechanics and Materials (Volume 658)
• Pages: 700-705
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.658.700
• Online since: October 2014
• Authors: Ciprian Radu Rad*, Olimpiu Hancu, Vistrian Maties, Ciprian Lapusan
• Keywords: Identification, Industrial Automation, Modeling, Pneutronics, Proportional Valve

References

[1] A. Nicolae, Mechatronic technology in the area of pneumatics - pneutronics, 6th Workshop on European Scientific and Industrial Collaboration on promoting Advanced Technologies in Manufacturing - WESIC`08, pp.335-341, Bucharest, 25-26 September, (2008).

[2] C. -R. Rad, O. Hancu and C. Lapusan, Gray-Box Modeling and Closed-Loop Temperature Control of a Thermotronic System, in The 11th IFToMM International Symposium on Science of Mechanisms and Machines, Springer International Publishing, pp.197-207, (2014).

DOI: 10.1007/978-3-319-01845-4_20

[3] J. Cao, X.C. Zhu, G.L. Tao and B. Yao, Adaptive robust tracking control of pressure trajectory based on Kalman filter, Chinese Journal of Mech, Engineering, vol. 22, pp.433-439, March, (2009).

DOI: 10.3901/cjme.2009.03.433

[4] M. Smaoui, X. Brun and D. Thomasset, A combined first and second order sliding mode approach for position and pressure control of an electropneumatic system, Proc. 2005 American Conf., pp.3007-3012, June, (2005).

DOI: 10.1109/acc.2005.1470432

[5] D. Meng, et al., Modeling of a pneumatic system for high-accuracy position control, International Conference on Fluid Power and Mechatronics (FPM), Beijing, (2011).

[6] S. Ning, G.M. Bone, Development of a nonlinear dynamic model for a servo pneumatic positioning system, in IEEE International Conference on Mechatronics and Automation, (2005).

DOI: 10.1109/icma.2005.1626520

[7] R. Zhihong, G.M. Bone, Nonlinear Modeling and Control of Servo Pneumatic Actuators, IEEE Transactions on Control Systems Technology, vol. 16, no. 3, pp.562-569, May, (2008).

DOI: 10.1109/tcst.2007.912127

[8] P. Beater, Pneumatic Drives: System Design, Modelling and Control, Springer-Verlag Berlin Heidelberg, (2007).

[9] P.G. Harris, G.E. O'Donnell and T. Whelan, Modelling and identification of industrial pneumatic drive system, The International Journal of Advanced Manufacturing Technology, no. 58, pp.1075-1086, (2012).

DOI: 10.1007/s00170-011-3447-7

[10] J. van der Merwe, Parameter Identification and Evaluation of a Proportional Directional Flow Control Valve Model, R&D Journal of the South African Institution of Mechanical Engineering, no. 29, pp.18-25, (2013).

[11] J.F. Carneiro and F.G. de Almeida, Reduced-order thermodynamic models for servo-pneumatic actuator chambers, Proceedings of the Institution of Mechanical Engineers Part I-Journal of Systems and Control Engineering, 220(I4), pp.301-314, March, (2006).

DOI: 10.1243/09596518jsce203
