Study on Swelling Solution for High Tg Epoxy Resin Substrate

Abstract:

A new type of swelling solution is developed, which is applied for the pre-treatment of plating-through-hole (PTH) of print circuit board (PCB) made up of high Tg epoxy resin substrates. The results show that the best formula is 144 organic esters 200g/L and hexylene glycol 2g/L. The treatment temperature and processing time is 60°C and 6min, respectively. Under the optimal conditions, the residue caused by drilling can be removed completely through the process including swelling, oxidation and neutralization.

• Periodical: Applied Mechanics and Materials (Volumes 66-68)
• Pages: 90-95
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.66-68.90
• Online since: July 2011
• Authors: Guo Fang Han, Jian Hua Shi, Zhi Dong Chen
• Keywords: Desmear, High Tg Epoxy Resin Substrate, Print Circuit Board, Swelling Solution

References

[1] Y.T. Gao, S. Tian and X. Xue: Elec. Pro. Tech., vol. 27(2006), p.91.

[2] Z. Chen, N. Mitsuzaki: Prin. Circ. Info., no. 6(2005), p.35.

[3] Z. Chen, X. Liang and N. Mitsuzaki: Prin. Circ. Info., no. 7(2003), p.42.

[4] Z. Sun: Prin. Circ. Info., no. 10(2003), p.33.

[5] I. Krakovsky, J. Hanus and J. Plestil: Pol., vol. 46(2005), p.109.

[6] L. Yang, B. SUN, Y. Xu, C. Chen and J. Li: Mem. Sci. Tech., vol. 28 (2008), p.44.

[7] P. Zhu, L. Ren, H. Yang and Y. Liu:. J. Func. Poly., vol. 16(2003), p.261.

[8] G. Z. Xiao and M. E. R. Shanahan: Poly., vol. 39 (1998) , p.3253.
