Study on Fatigue Crack Growth Model of 7075-T7410 Aluminum Alloy Straight Attachment Lug

Abstract:

The finite element model of a 7075-T7410 straight attachment lug is built by using the finite element software ANSYS, a cosine distribution pin-bearing pressure is applied on the surface of the pin-hole as a boundary condition. The stress intensity factor (SIF) expression for the straight attachment lug with a single through-the-thickness crack and subjected to an axial pin-load is determined by studying on the effect of the geometric parameters (the dimensionless crack length a/R₁，the ratio of outer radius to inside radius R₂/R₁ and the inside radius R₁) on SIF value. The fatigue crack growth velocity (da-dN) and the stress intensity factor’s amplitude (ΔK) is calculated by the SIFs equations to get the values of the Paris constants, offering an analytical method for establishment of the fatigue crack growth model of the typical straight lugs. The paper can be helpful in assessing and designing damage tolerant attachment lugs.

• Periodical: Applied Mechanics and Materials (Volumes 66-68)
• Pages: 82-89
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.66-68.82
• Online since: July 2011
• Authors: Li Ming Wu, Yu Ting He, Xin Bo Wang, Hai Wei Zhang, Jin Qiang Du, Hua Ding
• Keywords: Attachment Lug, Fatigue Crack Growth (FCG), Finite Element Model (FEM), Paris Law, Stress Intensity Factor (SIF)

References

[1] R. Rigby, M.H. Aliabadi: Stress Intensity Factors for Cracks at Attachment Lugs. Engineering Failure Analysis. Vol. 4 (1997), p.133~146.

DOI: 10.1016/s1350-6307(97)00004-6

[2] Jong-Ho Kim, Soon-Bok Lee, Seong-Gu Hong: Fatigue Crack Growth Behavior of Al7075-T7451 Attachment Lugs under Flight Spectrum Variation. Eng. Fract. Mech. Vol. 40(2003), p.135~144.

DOI: 10.1016/s0167-8442(03)00041-7

[3] A.F. Liu and H.P. Kan: Test and Analysis of Cracked lugs. Fracture. Vol. 3(1977), pp.567-664.

[4] D.J. Cartwright and D.P. Rooke: Approximate Stress Intensity Factors Compounded from Known Solutions. Engineering Fracture Mechanics. Vol. 6 (1974), p.563~571.

DOI: 10.1016/0013-7944(74)90013-7

[5] J. Schijve and A.H.W. Hoeymakers: Fatigue Crack Growth in Lugs and the Stress Intensity Factor. Report LR-273, Delft University of Technology, Delft, the Netherlands, July (1978).

[6] L.A. James and W.E. Anderson: A Simple Experimental Procedure for Stress Intensity Factor Calibration. Engineering Fracture Mechanics. Vol. 1 (1969), p.565~568.

DOI: 10.1016/0013-7944(69)90012-5

[7] T.H.H. Pian, J.W. Mar, O. Orringer and G. Stalk: Numerical Computation of Stress Intensity Factors for Aircraft Structural Details by the Finite Element Method. AFFDL-TR-76-12, Air Force Flight Dynamics Laboratory, May (1976).

[8] J. A. Aberson and J.M. Anderson: Cracked Finite-Elements Proposed for NASTRAN. Third NASTRAN Users' Colloquium, NASA TMX-2893 (1973), p.531~550.

[9] Xue Jingchuan: Bolt and Lug Strength Analysis Handbook (Aviation Industry Publications, China 1998).

[10] Gao Qing: Engineering Crack Mechanics (Chongqing University Publications, China 1986).

[11] Zheng Xiaoling: Civil Aircraft Durability and Damage Tolerance Design Handbook (Aviation Industry Publications, China 2003).

[12] Interpreted by Scientific and Technical Research Institute of Ministry of Aero-space Industry: USAF Damage Tolerance Design Handbook (Northwest Polytechnical University Publications, China 1989).
