Kalman Filter-Based Robot Manipulator Five-Degrees of Freedom Uncalibrated Vision Positioning

Abstract:

Robot manipulator position and posture control is a popular topic in the field of uncalibrated visual servoing, this paper presents a kalman filter-based robot manipulator five-degrees of freedom uncalibrated vision positioning method. In the case of the fixed binocular cameras and manipulator parameters are unknown; firstly, the specific point and angle image features information in the camera image space were selected in order to describe the relative pose relationship between robot manipulator ends and goals. Then, the kalman filter online estimation algorithm was applied to calculate image Jacobian matrix which is mapping relationship between image space to cartesian mission space, and vision controller was designed in the image plane realized robot manipulator five-degrees of freedom uncalibrated vision positioning control. Finally, Six-degrees of freedom robot manipulator’s five-degrees of freedom uncalibrated visual positioning Simulink model established in the Matlab environment, and the simulation result show that kalman filter online estimation method made the robot manipulator rapid convergence to the desired position and posture with high accuracy.

• Periodical: Applied Mechanics and Materials (Volumes 668-669)
• Pages: 347-351
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.668-669.347
• Online since: October 2014
• Authors: Lang Liu*, Niu Wang, Chu Zhong Yu, Da Tao Wang
• Keywords: Five-Degrees of Freedom, Image Jacobian, Kalman Filter, Robot Manipulator, Uncalibrated Vision Positioning

References

[1] Yoshimi B H, Allen P K. Robotics and Automation, IEEE Transactions on, 1995, 11(4).

[2] Liu YH, Wang HS, Wang C, Lam K. IEEE Tran Robotics 2006; 22(4): 804–17.

[3] Hesheng Wang, YunHui Liu, Weidong Chen. IEEE/ASME Trans Mechatron 2012; 22(6): 390–397.

[4] Youxin Li, Zongyuan Mao, Lianfang Tian. Control Theory & Applications, 2009, 26(10): 1162-1166. In Chinese.

[5] Xinjing, Liuding, XuQing kun. Control Theory & Applications, 2010, 27(1): 77-85. In Chinese.

[6] Jianbo Su. Huazhong Univ. of Sci. &Tech. (Nature Science Edition ), 2004(S1): 42-44. In Chinese.

[7] Xinjing, Bailei, Liuding. Journal of System Simulation, 2014, 26 (3): 586- 591. In Chinese.

[8] Liwei Han, Xude, Tanmin. Control and Decision, 2007, 22(1): 1-6. In Chinese.

[9] Weiss L E, Sanderson A C, Neuman C P. Robotics and Automation, IEEE Journal of, 1987, 3(5): 404-417.

[10] Information onhttp: /www. cs. unc. edu/ welch/kalman/kalmanIntro. html.

[11] Kalman, R. E. Transaction of the ASME—Journal of Basic Engineering, 1960. pp.35-45.
