Model-Based Design on the Application of Active Flow Control System

Abstract:

Active flow control has produced a great many values in the S-shaped inlets. In this study, the pressure gradient is used to characterize the degree of flow reattachment on the S-shaped inlet and be referred as the pressure recovery parameter^[1]. A transfer function is established between an input of frequency of the solenoid valve and an output of the pressure gradient. According to the process of model-based design, one of Simulink model created by Different Control Algorithms which are applied to the established system in the simulation is selected to generate C codes automatically. The generated codes are embedded in the ARM7 processor and the test result of the processor is consistent with simulation.

• Periodical: Applied Mechanics and Materials (Volumes 668-669)
• Pages: 478-481
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.668-669.478
• Online since: October 2014
• Authors: Liu Wu Shi*, Nai Ming Wu
• Keywords: Code Generation, Model-Based Design, Pressure Gradient, Simulink

References

[1] Brian G. Allan, Jer-Nan Juang : Closed-loop Separation Control Using Oscillatory Flow Excitation 2000(32).

[2] Pieter Monsterman, The Mathworks, Inc: Model-Based Design of Embedded Systems(2007).

[3] J. O Hallquist. LS-DYNA Theory Manual. Livermore Software Technology Corporation, March (2006).

[4] S. Nagahiro, Y. Hayakawa. Theoretical and Numerical Approach to Magic Angle, of Stone Skipping. Physical review letters, 94(17): 174501, 2005. 0 20 40 60 80 100 120 0.

DOI: 10.1103/physrevlett.94.174501

001.

002.

003.

004.

005.

006.

007.

008.

009.

01 0 20 40 60 80 100 120 30 35 40 45 50 55 60 65 70 simulation result ARM7 result.
