Modeling and Simulation of Boost Converter with Voltage Feedback Control

Abstract:

In order to achieve a proper design and control, it is necessary to have an exact model of boost converter. In this paper, the mathematic model of boost converter is proposed by the state-space average method. In the next step, the open-loop transfer function model without compensation is deduced in detail according to the mathematic model of the boost converter, the controller is designed according to frequency domain. The phase margin and magnitude margin of the open-loop system of the boost converter with compensator have both been increased. After compensating, the control system becomes stable. Using Matlab 7.1, the simulation of the control system of boost converter was implemented. The simulation results of control system confirm that the controller can reduce steady state error and resist power supply disturbance.

• Periodical: Applied Mechanics and Materials (Volumes 668-669)
• Pages: 482-485
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.668-669.482
• Online since: October 2014
• Authors: Qiang He
• Keywords: Bode Diagram, Boost Converter, Series Compensation, State-Space Averaging Method

References

[1] T. Nouri and E. Babaei: Electric Power Systems Research Vol. 105 (2013), pp.771-84.

[2] P. Petit, M. Aillerie, J.P. Sawicki and J.P. Charles: Energy Procedia Vol. 36 (2013), pp.642-649.

[3] M. E. Sahin, H. İ. Okumuş and M. T. Aydemir: International Journal of Hydrogen Energy (2014), in press.

[4] H. Komurcugil: Control Engineering Practice Vo1. 21 (2013), pp.321-332.

[5] A.S. Samosir: Simulation Modelling Practice and Theory Vol. 18 (2010), pp.663-676.

[6] H.M. Mahery and E. Babaei: Electrical Power and Energy Systems Vo1. 44 (2013), pp.949-963.

[7] Q.F. Liu Z.X. Leng and J. k. Sun: Physics Procedia Vo1. 24 (2012), p.2053-(2058).
