Study on Band Gap Varying of Diamond Photonic Crystals by Fabricating to Bring the Error of Dielectric Volume Fraction

Abstract:

To avoid the effect of the error of dielectric volume fraction brought by fabricating process on band gap, the diamond crystals with different the error of dielectric volume fraction were designed and fabricated to investigate the fluctuation of band gaps. Theses photonic crystals with a diamond structure were fabricated using alumina by stereolithography, gel-casting and sintering. The photonic band gaps were observed along <100> direction and the photonic band gaps were formed in different frequency range. Increasing the radius from 4.2mm to 4.32mm and changing band width from 0.8 to 1.39GHz, the radius is increased by 2.86%, and corresponding band width increased by 73.75%. Therefore, the fabrication error in mold and fabrication process including injecting mold, sintering should be maintained under the same conditions, which can retain the error of band gap.

You might also be interested in these eBooks

Applied Mechanics, Materials and Manufacturing IV

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 670-671)

Pages:

101-104

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.670-671.101

Citation:

Cite this paper

Online since:

October 2014

Authors:

Shi Bin Chen*, Yun Shi Yao, Xiao Hui Li, Min Jie Wang

Keywords:

Band Gap, Dielectric Volume Fraction, Fabrication Error, Photonic Crystal (PC)
