Operation and Control of a Microgrid Containing PV Cells and Battery

Abstract:

Microgrids are LV or MV electric networks which utilize various distributed generators (DG)to serve local loads. They could operate in either grid-connected or island mode, and hence increase the reliability of energy supplies. In this paper, dynamic models of photovoltaic cell were described in ElectroMagnetic Transient Program/Alternative Transients Program(EMTP/ATP).In addition, basic models of the equivalent power electronic interfaces and batteries were developed.The above models have been integrated in a microgrid to represent the dynamic characteristic of steady state and transient operation. When operated under steady state, the PV cells could be able to deliver power supply to the load via electronic interfaces. When fault,the battery with P/V and Q/f control strategy based on the droop characteristics was developed to isolate the microgrid from the main grid in a rapid and seamless way,which contributing effective control of voltage and enhancement of system stability. Simulation results verify the feasibility of the proposed models.

• Periodical: Applied Mechanics and Materials (Volumes 672-674)
• Pages: 66-70
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.672-674.66
• Online since: October 2014
• Authors: Xu Ri Song*, Xue Jing Chen, Miao Wang, Yang Bai, Jing Huai Lin, Ze Ke Li
• Keywords: Battery, Control Strategy, Microgrids (MGs), PV Cell

References

[1] F.D. Kanellos A.I. Tsouchnikas N.D. Hatziargyriou. Micro-Grid Simulation during Grid- Connected and Island Modes of Operation, presented at the International Conference on Power Systems Transients(IPST'05) in Montreal, Canada on June 19-23, 2005, Paper No: IPST05-113.

[2] Joanne Hui, Alireza Bakhshai, Praveen K. Jain. A Hybrid Wind-Solar Energy System: A New Rectifier Stage Topology, Applied Power Electronics Conference and Exposition(APEC), 2010 Twenty-Fifth Annual IEEE, 21-25 Feb. 2010, pp.155-161.

DOI: 10.1109/apec.2010.5433678

[3] Sotirios B. Skretas, Demetrios P. Papadopoulos. Efficient design and simulation of an expandable hybrid(wind-photovoltaic) power system with MPPT and inverter input voltage regulation features in compliance with electric grid requirements. Electric Power Systems Research 79(2009).

DOI: 10.1016/j.epsr.2009.03.010

[4] Mehdi Dali, Jamel Belhadj, Xavier Roboam. Design of a stand-alone hybrid Photovoltaic-Wind generating system with battery storage, http: /journal. esrgroups. org/jes/papers/4_3_7. pdf.

[5] LI Guangqi. Power System Transient Analysis. Beijing, China Electric Power Press. Sep. 2007, pp.30-40, In Chinese.
