Functions and Theoretical Basis of Partial Discharge On-Line Monitoring System for High-Voltage Cables

Abstract:

A partial discharge (PD) on-line monitoring and positioning system for high-voltage cables based on double-ended testing technology is developed. The hardware of this system includes a high-frequency current sensor, site PD signal acquisition and PD monitoring server. In order to achieve real-time monitoring and remote diagnostics of the XLPE cable partial discharge status, the designed software system is divided into front-end control system and remote diagnostic system. And finally, the correctness and effectiveness of the system is verified by XLPE cable partial discharge testing.

• Periodical: Applied Mechanics and Materials (Volumes 672-674)
• Pages: 854-857
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.672-674.854
• Online since: October 2014
• Authors: Dan Pang, Xi Lin Zhang, Zhen Hao Wang, Dan Zhang, Xiao Juan Han
• Keywords: Fault Location, High-Voltage Cable, Partial Discharge (PD)

References

[1] Lu Zhixiong, etc.: Hubei Electric Power, Vol. 2, No. 4 (2004), pp.32-35.

[2] Sui Huibin, etc.: Journal of Shandong University: Engineering Science, Vol. 42, No. 4 (2012), pp.126-131.

[3] Liu Pingyuan, etc.: High voltage engineering, Vol. 27, No. 4 (2001), pp.26-28.

[4] Luo Junhua, etc.: High voltage engineering, Vol. 25, No. 4 (1999), pp.32-34.

[5] Chen Qiaoyong, etc.: Insulating Materials, Vol. 4 (2003), pp.51-54.

[6] QIN Jian, etc.: International Electric Power For China, Vol. 4 (2001), pp.31-35.
