Research on Intelligent Actuation Control Technology of High-Speed Solenoid Valve

Abstract:

In order to develop actuation circuit for high pressure common rail injector solenoid valve, the high and low voltage time-sharing actuation control method based on current feedback was researched. A finite state machine tool called stateflow was used to establish the actuation model of solenoid, and the intelligent actuation control circuit was developed according to the model and MCU. The driving current can be adjusted automatically according to “Peak-High-Low” three-stage current, and the circuit can troubleshoot the state of solenoid. Driving Experiments on solenoid and injector were carried out and the results show the good performance of the intelligent actuation control circuit.
