Optimization the Arrangement of Power Cable Lines in Tunnel

Abstract:

In order to optimized the power cable layout design in tunnel, and improved the operation ability of the cable line, this paper analyzed the cable rating and the short-circuit force under different arrangements. 220kV cable circuit was simulated in the tunnel with conditions of the flat and the trefoil arrangements. The temperature and the rating of the 220kV cable under the condition of the two arrangements were calculated in this paper. The short circuit force peak value and its direction of the cable line under short circuit current of 50kA under the condition of the two arrangements were simulated in this paper. The results show that, the cable rating in flat arrangement is better than in trefoil formation. The value and the direction of the short circuit force in tunnel are better in flat arrangement than in trefoil formation. So it is suggested that the flat arrangement is preferred when conditions permit.

• Periodical: Applied Mechanics and Materials (Volume 678)
• Pages: 513-517
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.678.513
• Online since: October 2014
• Authors: Guang Hua He*, Zhen Peng Zhang, Min Sheng Xie, Ying Xiong Wu, Dong Xing Yang, Jun Xu, Kai Xu
• Keywords: Cable Rating, Flat Arrangement, High Voltage Cable, Operating Temperature, Short Circuit Force, Trefoil Formation

References

[1] Cable Systems Electrical Characteristics [R]．Report of CIGRE WG B1-30: 2013.

[2] Cable Systems in Multipurpose or Shared Structures[R]．Report of CIGRE WG B1-08: 2010.

[3] Asset Management of Transmission Systems and Associated CIGRE Activities[R]．Report of CIGRE WG C1-1: 2006.

[4] ZHANG Zhenpeng, ZHAO Jiankang, RAO Wenbin, et al．Validate Test for the Calculation congruity of Distributed temperature Sensing System[J], High Voltage Engineering, 2012, 38(6): 1362-1367.

[5] Construction, laying and installation techniques for extruded and self-contained fluid filled cable systems[R]．Report of CIGRE WG 21-17: 2001.

[6] IEC62067．Power cable with extruded insulation and their accessories for rated voltages above 150kV(Um=170 kV) up to 500 kV(Um=550 kV)—Test methods and requirements[S], 2001.

DOI: 10.3403/30078182

[7] Z.X. Feng．The treatment of singularities in calculation of magnetic field by using integral method．IEEE Transactions on magnetics, 1985, 21(6): 2207-2210.

DOI: 10.1109/tmag.1985.1064259

[8] Labridis D., Dokopoulos P. ．Finite element computation of field, losses and forces in a three-phase gas cable with nonsymmetrical conductor arrangement． IEEE Transactions on Power Delivery, 1988, 3(4): 1326-1333.

DOI: 10.1109/61.193927

[9] Zheng Zhaoji, Wang Kunming. Power Cable Line [M]. Beijing, China：Water Conservancy and Electric Power Press, (1983).

[10] IEC 60853．Calculation of the Cyclic and Emergency Current Rating of Cable[S], 2002.

[11] IEC 60287．Electric cable-calculation of the current rating[S], 2002.

[12] Zhang Zhenpeng, Zhao Jiankang, Yang Feng, et al．Power Cable Emergency Loading Emulate Calculation and Test Research [J], High Voltage Engineering, 2011, 37(s).
