Study on TMD Measure to Suppress Wind-Induced Vibration of Power Transmission Steel Tower

Abstract:

Wind-induced vibration can affect the safety of power transmission tower. Vibration suppression of the high-rise tower is of concern in engineering. Vibration of the tower is mostly the first-order bending modal and this vibration can be suppressed by the tuned mass damper (TMD). This paper developed a TMD vibration damping device using eddy current damper constituted by magnetic steel installed in the vibration mass and fixed copper plate. It is characterized by simple structure and easy installation, and is suitable for wind-induced damage prevention of transmission tower. Focusing on a quadruple-circuit on the same steel tube tower, a vibration reduction test on a real-scale tower conducted. The result shows that the damping ratio of the tower after installed with the TMD device will increase about 3%. The actual test result verifies the effectiveness of the eddy current TMD device.

You might also be interested in these eBooks

Proceedings of 2014 International Conference on Mechanics and Mechanical Engineering

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 684)

Pages:

202-207

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.684.202

Citation:

Cite this paper

Online since:

October 2014

Authors:

Jing Bo Yang*, Zheng Qing Chen, Xu Gang Hua

Keywords:

Eddy Current Damper, Transmission Steel Tower, Tuned Mass Damper (TMD), Vibration Suppression, Wind-Induced Vibration

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] DL/T5154-2012, Technical Code for the Design of Tower and Pole Structures of Overhead Transmission Line[S]. Beijing: China Electric Power Press, 2012. (In Chinese).

Google Scholar

[2] Yang Jing-bo, Han Jun-ke, Li Mao-hua. Selection of Calculation Model for Steel Tubular tower of UHV Power Transmission Line[J], Power System Technology , Vol. 34(1): 1-5, 2010. (In Chinese).

Google Scholar

[3] T.T. Soong, G.F. Dargush. Passive Energy Dissipation Systems in Structural Engineering [M]. Science Press, 2005. (In Chinese).

Google Scholar

[4] Yang Jing-bo, Han Jun-ke, Hua Xu-gang, Chen Zheng-qing, Wind-induced Vibration Suppression of Tubular Towers for 1000kV Double-circuit Transmission Lines on the Same Tower From Huainan to Shanghai[J]. Proceeding of the CSEE, Vol. 30 (7): 104-108. (In Chinese).

Google Scholar

[5] Cao Shu-qian, Zhang Wen-de, Xiao Long-xiang, Structure Vibration Modal Analysis: Theory, Experiment and Application [M], Tianjin University Press, 2001. (In Chinese).

Google Scholar
