Structure and Nanoscale Polarization Switching Induced by High Frequency Alternating Current in PbTiO₃ Polycrystalline Films

Abstract:

PbTiO₃ (PTO) films were successfully fabricated by sol-gel method. We studied the structure and the nanoscale polarization switching property using XRD and Piezoresponse Force Microscopy. The results reveal that the PTO films are single perovskite phase grain films with tetragonal structure, and are polycrystalline materials with no evidence of preferential orientation. The average grain size is about 150nm and a striped multi-domain structure is exhibited in individual grains. Under 15 kHz alternating current of PFM, a significant asymmetry of switching pattern was observed. We suggest that the cooperative action of the built-in electric field at the bottom interface and the PFM ac-voltage lead to the asymmetry switching.

• Periodical: Applied Mechanics and Materials (Volumes 687-691)
• Pages: 4395-4398
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.687-691.4395
• Online since: November 2014
• Authors: Hui Fen Guo*, Shu Xia Guo
• Keywords: Domain Structure, PbTiO₃, Polarization Switching

References

[1] J. F. Scott Applications of modern ferroelectrics, Science [J]. 2007: 315 954-959.

[2] V. Garcia, S. Fusil, K. Bouzehouane, S. Enouz-Vedrenne, N. D. Mathur, A. Barthelemy and M. Bibes Giant tunnel electroresistance for non-destructive readout of ferroelectric states, Nature [J]. 2009: 460 81-84.

DOI: 10.1038/nature08128

[3] X. Ren Large electric-field-induced strain in ferroelectric crystals by point-defect-mediated reversible domain switching, Nat Mater [J]. 2004: 3 91-94.

DOI: 10.1038/nmat1051

[4] Y. H. Chu, L. W. Martin, M. B. Holcomb, M. Gajek, S. J. Han, Q. He, N. Balke, C. H. Yang, D. Lee, W. Hu, Q. Zhan, P. L. Yang, A. Fraile-Rodriguez, A. Scholl, S. X. Wang and R. Ramesh Electric-field control of local ferromagnetism using a magnetoelectric multiferroic, Nat Mater [J]. 2008: 7 478-482.

DOI: 10.1038/nmat2184

[5] P. Maksymovych, S. Jesse, P. Yu, R. Ramesh, A. P. Baddorf and S. V. Kalinin Polarization control of electron tunneling into ferroelectric surfaces, Science [J]. 2009: 324 1421-1425.

DOI: 10.1126/science.1171200

[6] S. M. Wu, S. A. Cybart, M. D. R. P. Yu, J. X. Zhang, R. Ramesh and R. C. Dynes Reversible electric control of exchange bias in a multiferroic field-effect device, Nat Mater [J]. 2010: 9 756-761.

DOI: 10.1038/nmat2803

[7] E. Soergel Piezoresponse force microscopy (PFM), Journal of Physics D: Applied Physics [J]. 2011: 44 464003-01-17.

DOI: 10.1088/0022-3727/44/46/464003

[8] H. Lu, C. -W. Bark, D. E. d. l. Ojos, J. Alcala, C. B. Eom, G. Catalan and A. Gruverman Mechanical Writing of Ferroelectric Polarization, Science [J]. 2012: 336 59-61.

DOI: 10.1126/science.1218693

[9] A. L. Kholkin, V. V. Shvartsman, A. Y. Emelyanov, R. Poyato, M. L. Calzada and L. Pardo Stress-induced suppression of piezoelectric properties in PbTiO3: La thin films via scanning force microscopy, Applied Physics Letters [J]. 2003: 82 2127-2129.

DOI: 10.1063/1.1565177

[10] A. Gruverman, B. J. Rodriguez, A. I. Kingon, R. J. Nemanich, A. K. Tagantsev, J. S. Cross and M. Tsukada Mechanical stress effect on imprint behavior of integrated ferroelectric capacitors, Applied Physics Letters [J]. 2003: 83 728-730.

DOI: 10.1063/1.1593830

[11] S. Kalinin and D. Bonnell Imaging mechanism of piezoresponse force microscopy of ferroelectric surfaces, Physical Review B [J]. 2002: 65 125408-1-5.

DOI: 10.1103/physrevb.65.125408

[12] S. Kalinin, E. Karapetian and M. Kachanov Nanoelectromechanics of piezoresponse force microscopy, Physical Review B [J]. 2004: 70 184101-1-4.

DOI: 10.1103/physrevb.70.184101
