Excess Heat Power Measurement by Heat-Flow Calorimeter in a D/Pd Gas-Loading System

Abstract:

In order to confirm the reliability and accuracy of the excess heat triggered by current in the previous work [1-3], a new designed and built heat-flow calorimeter [4] was introduced in the same D/Pd gas-loading system as mentioned previously. The calorimeter was calibrated in nitrogen atmosphere and the results between the input power (P) and the exothermal electromotive force (V) could be simulated by a quadratic equation: P = (15.356 ± 0.068) V – (0.014 ± 0.039) V². The maximum excess power (6.398 ± 0.191 W) were found at the condition of an optimum current (8.47 A) and a deuterium pressure (3 × 10⁴ Pa). The reproducibility was 3/3 and the total excess energy released in these experiments was about 0.70 ± 0.02 MJ within 40 hours, which means (1.6 ± 0.1) ×10³ eV for each palladium atom. The excess heat power and excess heat energy were far more than that in a chemical reaction.

• Periodical: Applied Mechanics and Materials (Volumes 687-691)
• Pages: 874-877
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.687-691.874
• Online since: November 2014
• Authors: Bing Jun Shen, Xing Ye Wang, Wu Shou Zhang, Li Hong Jin, Xin Le Zhao, Dan Zhou, Xin Lu, Ling Yu Li, Jian Tian*
• Keywords: Current Triggering, D/Pd Gas-Loading System, Excess Heat Power, Heat-Flow Calorimeter

References

[1] J. Tian, X. Lu, L.H. Jin, B.J. Shen, L.Z. Zhu, X.L. Zhao, H.Y. Wang, X.H. Zheng and H.Y. Zhang. An excess heat phenomenon triggered by pressure in a H/Pd gas-loading system. Advanced Materials Research, 399-401(2012) 1433-1438.

DOI: 10.4028/www.scientific.net/amr.399-401.1433

[2] X. Lu, J. Tian, Lihong Jin, Bingjun Shen and Hongyu Wang. Excess heat production in a D/Pd system. Applied Mechanics and Materials, 161 (2012) 224-228.

DOI: 10.4028/www.scientific.net/amm.161.224

[3] Xin Lu, Bingjun Shen, Lihong Jin, Xinle Zhao, Hongyu Wang and Jian Tian. Excess Heat Triggered by Different Current in a D/Pd Gas-loading System. Journal of Energy and Power Engineering, 7 (2013) 1299-1303.

[4] W.S. Zhang. Construction, calibration and testing of a decimetre-size heat-flow calorimeter. Thermochimica Acta, 499 (2010) 128-132.

DOI: 10.1016/j.tca.2009.11.013

[5] S. Focardi, V. Gabbani, V. Montalbano. Large excess heat production in Ni-H systems. IL Nuovo Cimento A, 111 (1998) 1233-1242.

DOI: 10.1007/bf03545791
