Numerical Studies of Reinforced Concrete Beam Damage Detection Based on the Piezoelectric Impedance and Neural Network Technology

Abstract:

Aiming at the problem of reinforced concrete structure crack damage detection, an algorithm of crack damage monitoring based on the piezoelectric impedance technology was presented in this paper. With a piezoelectric coupling beam model was established, the electrical impedance equation of piezoelectric coupling beam was derived. The finite element model of reinforced concrete beam pasting with piezoelectric ceramic piece was established. The effect of different crack depth on the electrical impedance of coupling beam was analyzed. The results show that with the increase of crack depth, impedance peak decreases, spectrum shift to the left; neural network technology data processing method was used to the location identification of reinforced concrete beam crack depth. It proves that the piezoelectric impedance technology can successfully identify the degree of reinforced concrete beam damage to some extent.

• Periodical: Applied Mechanics and Materials (Volumes 687-691)
• Pages: 920-924
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.687-691.920
• Online since: November 2014
• Authors: Jun Zhang*, Jie Huang, Hong Mei Tang, Xian Hua Li, Xian Wen Zhao
• Keywords: Damage Detection, Finite Element, Neural Network, Piezoelectric Impedance

References

[1] Li Hong-nan, Li Dong-sheng. Safety assessment, Health Monitoring and Damage Diagnosis for Structures in Civil Engineering[J]. EARTHQUAKE ENGINEERING AND ENGINEERING . 2002, 22(3): 82-90.

[2] Liang C, Sun F P, Rogers C A. Electro-mechanical impedance modeling of active material systems[J]. Journal of Intelligent Material Systems and Structures. 1994, 21(3): 232-252.

[3] Liang C, Sun F P, Rogers C A. An impedance method for dynamic analysis of active material system[J]. IEEE Transactions of the ASME. 1994, 116(1): 120-128.

[4] Liang C, Sun F P, Rogers C A. Coupled electromechanical analysis of adaptive material system-Determination of the actuator power consumption and system energy transfer[J]. Journal of Intelligent Material Systems and Structures. 1994, 5(1): 12-20.

DOI: 10.1177/1045389x9400500102

[5] Zhang Jianwen. Research on Welding Structure Health Monitoring Using Piezoelectric Impedance Technology[D]. Nanjing University of Aeronautics and Astronautics. (2010).

[6] Gao Jian. Application Research of Structure Health Monitoring by Using BP Network and Piezoelectric Impedance Technology[D]. Nanjing University of Aeronautics and Astronautics. (2008).

[7] Wang Dansheng , Zhu Hongping , Chen Xiaoqiang , Zhou Jianfeng. Experimental Study on Damage Identification in a Cracked Beam Through Piezoelectric Self-Sensing Actuators[J]. JOURNAL OF VIBRATION AND SHOCK 2006(6): 139-142.

[8] Wu Jianzhong. The Finite Element Analysis of Damage Identification based on Piezoelectric Impedance[D]. Anhui University of Science and Technology. (2011).

[9] Gao Qin. The Research of Piezoelectric Impedance Technology Applying to the Dynamic Signal Beam[D]. Anhui University of Science and Technology. (2012).

[10] Tao Juan. The study of structure health diagnosis based on the EMI and the ANN technology[D]. Anhui University of Science and Technology. (2013).
