Harmonic Performance of Grid-Connected PV System under Various Penetration Levels

Abstract:

This paper studies the harmonic performance of grid-connected PV system under various penetration levels. The system under study was modelled in MATLAB/Simulink environment. Current and voltage distortions were studied in terms of the percentage of Total Harmonic Distortion (THD) under different PV penetration scenarios. The results showed that the Grid-Connected PV generates a different level of harmonics distortion depending on the PV penetration level that was injected to the grid.

• Periodical: Applied Mechanics and Materials (Volume 699)
• Pages: 486-491
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.699.486
• Online since: November 2014
• Authors: Munirah Ayub, Chin Kim Gan, Aida Fazliana Abdul Kadir
• Keywords: Grid-Connected PV, Harmonic, MATLAB/SIMULINK, Penetration Level, THD

References

[1] M. Hojo and T. Ohnishi, Adjustable Harmonic Mitigation for Grid-Connected Photovoltaic System Utilizing Surplus Capacity of Utility Interactive Inverter. 37th IEEE Power Electronics Specialists Conference. (2006) 1–6.

DOI: 10.1109/pesc.2006.1712025

[2] P. Kirawanich, Potential Harmonic Impact of a Residential Utility-Interactive Photovoltaic System. (2000) 983–987.

[3] S. R. Nandurkar and M. Rajeev, Design and Simulation of three phase Inverter for grid connected Photovoltic systems, (2012) 80–83.

[4] I. T. Papaioannou, A. S. Bouhouras, A. G. Marinopoulos, M. C. Alexiadis, C. S. Demoulias, and D. P. Labridis, Harmonic Impact of Small Photovoltaic Systems Connected to the LV Distribution Network. (2008).

DOI: 10.1109/eem.2008.4579061

[5] V. Khadkikar, R. K. Varma, R. Seethapathy, a. Chandra, and H. Zeineldin, Impact of distributed generation penetration on grid current harmonics considering non-linear loads. 2012 3rd IEEE International Symposium on Power Electronics for Distributed Generation Systems (PEDG) (2012 ) 608–614.

DOI: 10.1109/pedg.2012.6254065

[6] J. R. Agüero and F. Katiraei, Q U A N TA Impact Studies and Mitigation Measures for Integration of Solar Photovoltaic Distributed Generation Impact Studies and Mitigation Measures for Integration of Solar Photovoltaic Distributed Generation.

[7] M. Thomson, D. G. Infield, and S. Member, Network Power-Flow Analysis for a High Penetration of Distributed Generation, IEEE Transaction on Smart Grid. 2(2012) 1157- 1162.

DOI: 10.1109/tpwrs.2007.901290

[8] A. K. Srivastava, S. Member, A. A. Kumar, S. Member, and N. N. Schulz, Impact of Distributed Generations with Energy Storage Devices on the Electric Grid. IEEE System Journal. 1 (2012) 110–117.

DOI: 10.1109/jsyst.2011.2163013

[9] G. Chicco, J. Schlabbach, and F. Spertino, Characterisation and Assessment of the Harmonic Emission of Grid-Connected Photovoltaic Systems. (2004) 1–7.

DOI: 10.1109/ptc.2005.4524744
