Fabrication of Organic Dye Sensitized Solar Cell

Abstract:

Renewable energy is rapidly gaining importance as an energy resource to help aid the national energy depletion crisis of fossil fuel and coal. One of the most potential renewable energy sources in Malaysia is hydropower followed by solar energy. This paper presents the fabrication of Dye Sensitized Solar Cell (DSSC) using organic dyes from dragon fruit and chlorophyll which is extracted from spinach. The fabrication of DSSC uses the Dr.blade method. Result shows that the efficiency by using dragon fruit as sensitizer at 40µm TiO₂ Thickness is 6.45%, better than the usage of chlorophyll dye which is 4.23% at the same thickness. Result also shows that at 80µm by using the dyes from chlorophyll extract has higher solar cell efficiency compare to dragon fruit. This shows that both the chlorophyll extract and dragon fruit shows potential in the development of a feasible working organic dye.

You might also be interested in these eBooks

Sustainable Energy and Development, Advanced Materials

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 699)

Pages:

516-521

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.699.516

Citation:

Cite this paper

Online since:

November 2014

Authors:

Gomesh Nair*, Syafinar Ramli, Muhammad Irwanto, Mohd Irwan Yusoff, Muhammad Fitra, Uda Hashim, Norman Mariun

Keywords:

Dye-Sensitized Solar Cell (DSSC), Fabrication, Organic Dye, Solar Cell

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Renewable energy in South East Asia, July 2012 [Online] Available, http: /www. slideshare. net/Ipsosbc/an-ipsospaperonrenewableenergyinsoutheastasiajuly (2012).

Google Scholar

[2] D. Martineau. (2012), Dye Solar Cells for Real [Online]. Available: http: /creativecommons. org/licenses/by-nc-sa/3. 0/. [Acess on Jan 2013].

Google Scholar

[3] H. Chang, Y. J. Lo, Pomegranate leaves and mulberry fruit as natural sensitizers for dye-sensitized solar cells, Solar Energy 84 (2010) 1833-1837.

DOI: 10.1016/j.solener.2010.07.009

Google Scholar

[4] N.T.R.N. Kumara et al., Layered co-sensitization for enhancement of conversion efficiency of natural dye sensitized solar cells, Journal of Alloys and Compounds 581 (2013) 186–191.

DOI: 10.1016/j.jallcom.2013.07.039

Google Scholar

[5] M. S. Abdel-Latif, T. M. El-Agez, S. A. Taya, A. Y. Batniji and H. S. El-Ghamri, PlantSeeds-Based Dye-Sensitized Solar Cells, Materials Sciences and Applications, 2013, 4, 516-520.

DOI: 10.4236/msa.2013.49063

Google Scholar

[6] H. Chang, H.M. Wu, T.L. Chen, K.D. Huang, C.S. Jwo and Y. J Lo, Dye-sensitized solar cell using natural dyes extracted from spinach and ipomea, Jounal of Alloys and Compounds 495 (2010) 606-610.

DOI: 10.1016/j.jallcom.2009.10.057

Google Scholar

[7] E. M. Jin, Kyung-Hee Park, B. Jin, Je-Jung Yun and Hal-Bon Gu, Photosensitization of nanoporous TiO2 films with natural dye, Phys. Scr. T139 (2010) 014006 (5pp).

DOI: 10.1088/0031-8949/2010/t139/014006

Google Scholar

[8] H. Chang, Mu-Jung Kao, Tien-Li Chen, Chih-Hao Chen, Kun-Ching Cho and Xuan-Rong Lai, Characterization of Natural Dye Extracted from Wormwood and Purple Cabbage for Dye-Sensitized Solar Cells, International Journal of Photoenergy Volume 2013, Article ID 159502, 8 pages.

DOI: 10.1155/2013/159502

Google Scholar

[9] A. Gleue, (2008). Building the Grätzel Solar Cell. Available: http: /www. nlcpr. com/GratzelSolarCell. pdf [Acess on Jan 2013].

Google Scholar

[10] M. Murugiah, Jamil Hashim, U. Nirmal, and M. Y. Yuhazri, Synthesis and Fabrication of an Effectual Dye Sensitized Solar Cell, vol. 2, pp.9-15, (2012).

Google Scholar
