Airborne Multispectral Imager Used in the UAV

Abstract:

Under existing conditions, the use of optical lens, imaging spectrometer, and the establishment of a rectangular CMOS image sensor spectral imaging system. Wide spectrum of white LED illuminated sample, by ordinary optical imaging lens, then the multi-channel narrowband filter array on the image plane splitting, and finally by the CMOS image acquisition system, converting optical signals into electrical signals, and then converted by the analog-digital converter chip to a digital signal to the computer. Finally, computer-spectral image cube collected for processing. At the same time, the advantages of airborne multispectral imager used in the UAV trials, obtain higher picture quality, and maintain a portable, imaging speed, and further validate the reliability of the experimental system.

• Periodical: Applied Mechanics and Materials (Volumes 701-702)
• Pages: 283-287
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.701-702.283
• Online since: December 2014
• Authors: Chun Yu Wang*, Qing Wei Dong, Yang Li, Xin Yue Xie
• Keywords: Multispectral Imaging, Spectral Imaging Principle, Spectral Imaging System, UAV Applications

References

[1] Jingbo Zhang. Uranium. Vol. l7, N0. 5: 307-313(2001). In Chinese.

[2] Fangxing Dai, Rong Shu, Binyong Wang, He Zhiping. Infrared Technology. Vol. 29 No. 8: 466-471(2007) In Chinese.

[3] Binyong Wang, Rong Shu, Jianjun Jia, Kangmei Fang, Fangxing Dai. Optics & Optoelectronic Technology. Vol. 2, No. 2: 18-20(2004). In Chinese.

[4] Xiaoxia Zhao, Wenfeng Luo, Yuanyuan Li. Journal of Xi an University of Arts ＆ Science(Nat Sci Ed)., Vol. 15 No. 4: 20-22(2012) , In Chinese.

[5] Guohua Li, Yantao Pang, Zuoxiao Dai. Optoelectronics·Laser. Vol. 12 No. 2: 141-143(2001) In Chinese.
