Influence of Nonlinear Stiffness on the Dynamics of a Slender Elastic Beam under Torsional Oscillations

Abstract:

This study focuses on analysing the effects of nonlinear torsional stiffness on the dynam-ics of a slender elastic beam under torsional oscillations, which can be subject to helical buckling.The helical buckling of an elastic beam confined in a cylinder is relevant to many applications. Someexamples include oil drilling, medical cateters and even the conformation and functioning of DNAmolecules. A recent study showed that the formation of the helical configuration is a result of onlythe torsional load, confirming that there is a different path to helical buckling which is not related tothe sinusoidal buckling, stressing the importance of the geometrical behaviour of the beam. A lowdimensional model of an elastic beam under torsional oscillations is used to analyse its dynamical be-haviour with different stiffness characteristics, which are present before and after the helical buckling.Hardening and softening characteristics are present, as the effects of torsion and bending are coupled.With the use of numerical algorithms applied to nonlinear dynamics, such as bifurcation diagramsand basins of attraction, it is shown that the nonlinear stiffness can shift the bifurcations and inducechanges in the stability of the desirable and undesirable solutions. Therefore, the proper modellingof these stiffness nonlinearities seems to be important for a better understanding of the dynamicalbehaviour of such beams

• Periodical: Applied Mechanics and Materials (Volume 706)
• Pages: 159-169
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.706.159
• Online since: December 2014
• Authors: Marcos Silveira, Bento R. Pontes, José Manoel Balthazar
• Keywords: Nonlinear Stiffness, Slender Beams, Torsional Oscillation

References

[1] A. Lubinski, W.S. Althouse, J.L. Logan, Helical buckling of tubing sealed in packers, Petroleum Transactions, 1962, 655-670.

DOI: 10.2118/178-pa

[2] N.C. Huang, P.D. Pattillo, Helical buckling of a tube in an inclined wellbore, International Journal of Non-Linear Mechanics, 35, 2000, 911-923.

DOI: 10.1016/s0020-7462(99)00067-0

[3] G.H.M. Heijden, The static deformation of a twisted elastic rod constrained to lie on a cylinder, Proceedings of the Royal Society A, 457, 2001, 695-715.

DOI: 10.1098/rspa.2000.0688

[4] M. Silveira, M. Wiercigroch, Low dimensional models for stick-slip vibration of drill-strings, Journal of Physics: Conference Series, 181, (2009).

DOI: 10.1088/1742-6596/181/1/012056

[5] J.M.T. Thompson, M. Silveira, G.H.M. Heijden, M. Wiercigroch, Helical post-buckling of a rod in a cylinder: with applications to drill-strings, Proc. R. Soc. Lond. A, 468, 1591-1614, (2012).

DOI: 10.1098/rspa.2011.0558

[6] A.P. Christoforou, A.S. Yigit, Dynamic modelling of rotating drillstrings with borehole interactions, Journal of Sound and Vibration, 206. 243-260, (1997).

DOI: 10.1006/jsvi.1997.1091

[7] J.D. Jansen, L. Steen, L., Active damping of self-excited torsional vibrations in oil well drillstrings, Journal of Sound and Vibration, 179, 257-279, (1995).

DOI: 10.1006/jsvi.1995.0042

[8] A.S. Yigit, A.P. Christoforou, Coupled axial and transverse vibrations of oilwell drilltrings, Journal of Sound and Vibration, 195, 617-627, (1996).

DOI: 10.1006/jsvi.1996.0450

[9] T. Richard, C. Germay, E. Detournay, A simplified model to explore the root cause of stick-slip vibrations in drilling systems with drag bits, Journal of Sound and Vibration, 305, 432-456, (2007).

DOI: 10.1016/j.jsv.2007.04.015

[10] A.S. Yigit, A. P Christoforou, Coupled torsional and bending vibrations of drilltrings subject to impact with friction, Journal of Sound and Vibration, 215, 167-181, (1998).

DOI: 10.1006/jsvi.1998.1617

[11] J. Wojewoda, A. Stefanski, M. Wiercigroch, T. Kapitaniak, T., Hysteretic effects of dry friction: modelling and experimental studies, Philosophical Transactions of the Royal Society A, 366, 747-765, (2008).

DOI: 10.1098/rsta.2007.2125

[12] M. Bernardo, C.J. Budd, A.R. Champneys, P. Kowalczyk, Piecewise-smooth dynamical systems, Springer-Verlag, London, (2008).

[13] U. Galvanetto, U., Sliding bifurcations in the dynamics of mechanical systems with dry friction - remarks for engineers and applied scientists, Journal of Sound and Vibration, 276, 121-139, (2004).

DOI: 10.1016/j.jsv.2003.07.017

[14] K. Popp, M. Rudolph, Vibration control to avoid stick-slip motion, Journal of Vibration and Control, 10, 1585-1600, (2004).

DOI: 10.1177/1077546304042026

[15] M. Wiercigroch, A note on the switch function for the stick-slip phenomenon, Journal of Sound and Vibration, 175, 700-704, (1994).

DOI: 10.1006/jsvi.1994.1559

[16] R. I Leine, D.H. Campen, D. H., Bifurcation phenomena in non-smooth dynamical systems, European Journal of Mechanics A/Solids, 25, 596-616, (2006).

DOI: 10.1016/j.euromechsol.2006.04.004
