A Photo-Curing Method to Prepare Biomimetic Micro-Nano Structure of Butterfly Wing Scale

Abstract:

It has been well-known that butterfly wings possess interesting optic properties. Recently, dendritic micro-nanostructure has been found in the wing scales of butterfly Trogonoptera brookiana, which shows excellent light-trapping effect, especially for the visible light. When light enters such a dendritic micro-nanostructure, it will be trapped and eventually absorbed by multiple reflections to generate heat. It is desirable to prepare a biomimetic structure resembling the micro-nanostructure of the butterfly wing scale, which may lead to a new material that can potentially improve the light utilization rate of solar thermal heater and other similar applications. However, a convenient method to make such a structure in large scale is still lacking. Herein, an easy and handy approach has been developed to prepare biomimetic dendritic structure. The starting material is negative photoresist, a chemical reagent which is widely used in photography. A simple device that can adjust the intensity and interval of ultraviolet illumination has been designed and set up. A periodic structure has been achieved via photo-curing with ultraviolet light and the ratio of illumination time has been optimized.

• Periodical: Applied Mechanics and Materials (Volumes 713-715)
• Pages: 2576-2580
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.713-715.2576
• Online since: January 2015
• Authors: Wei Wang, Gang Wang, Ping She, Hang Sun, Zhen Ning Liu*
• Keywords: Biomimetic, Butterfly Wing Scale, Micro-Nanostructure, Negative Photoresist, Photo-Curing

References

[1] Lippert W, Gentil K. Uber lamellare feinstrukturen bei den schillershuppen der schmetterlinge vom uraniaund morpho-typ [J]. Zoomorphology. 1959, 48: 115-122.

DOI: 10.1007/bf00407836

[2] Land M F. The physics and biology of animal reflectors [J]. Progr. Biophys. Mol. Biol, 1972, 24: 75-106.

[3] Ghiradella H. Development of ultraviolet- reflecting butterfly scales: how to make an interference filiter [J]. Morphol, 1974, 142: 395- 410.

DOI: 10.1002/jmor.1051420404

[4] Downey J C, Allyn A C. Wing-scale morphology and nomenclature [J]. Bull. Allyn. Mus, 1975, 31: 1-32.

[5] Tada H, Mann S E, Miaoulis I N, et al. Effects of a butterfly scale microstructure on the iridescent color observed at different angles [J]. Optics Express, 1999, 5: 87-92.

DOI: 10.1364/oe.5.000087

[6] Niu S, Shang C, Liu Z et al. Light trapping structures in wing scales of butterfly Trogonoptera brookiana [J]. Nanoscale, 2012, 4: 2879-2883.

DOI: 10.1039/c2nr12059c

[7] Niu S, Zhang L, Liu Z et al. Light Trapping Effect in Wing Scales of Butterfly Papilio peranthus and Its Simulations [J]. Journal of Bionic Engineering, 2013, 10: 162-169.

DOI: 10.1016/s1672-6529(13)60211-5

[8] Wu L Y, Han Z W, Song Y Q, et al. Replication of Papilio maackii Ménétriés butterfly scale structural color using a magnetron sputtering method [J]. Chin. Sci. Bull, 2012, 57, 3111-3114.

DOI: 10.1007/s11434-011-4898-9

[9] He J J, Zhou Z J, Wu S X. A simple approach toward preparation of Light anode material with butterfly wings as templates [C]. Chinese Chemical Society 27th Academic Annual Meeting, Xiamen, 2010, 133-135.

[10] Li J, Xie H M, Luo Q, et al. Fabrication technique of micro/nano-scale speckle patterns with focused ion beam [J]. Sci. China, 2012, 55: 1037-1044.

DOI: 10.1007/s11433-012-4751-4

[11] Xia Q. Optimal design for biomimetic micro-nano structures on Morpho butterfly wing [J]. Journal of Huazhong University of Science and Technology, 2012, 5: 10-14.
