A Hybrid Differential Flatness and Sliding Modes Controller for Dynamical Structural Testing on Lower Limp Prostheses

Abstract:

The standard ISO 10328 specifies the procedure for structural tests on lower limb prosthetic devices, as a method for quality control. Having the standard as reference, a machine is designed and implemented to follow the test routine, which if succeeded, shows the quality concept for the devices tested. Furthermore, it is shown the controller design process, which manage the application of a sinusoid force with specified amplitude, frequency and offset, in order to realize the dynamic test, by means of a double effect cylinder and proportional valves for pressure and flow.The dynamic model was calculated through a parametric identification technique in a pre-stabilized closed loop. Later, a hybrid control strategy was set using the differential flatness concept and a sliding modes controller, so that both identified model and real system could be properly controlled.

• Periodical: Applied Mechanics and Materials (Volumes 713-715)
• Pages: 777-780
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.713-715.777
• Online since: January 2015
• Authors: Mauricio M. Mauledoux, Oscar I. Caldas, Oscar F.S. Avilés, Edilberto Mejía-Ruda, Sebastián Jiménez
• Keywords: Differential Flatness, Lower Limp Prostheses, PID Controller, Sliding Modes, Testing

References

[1] ISO (International Organization for Standardization). Prosthetics – Structural testing of lower limb prostheses – Requirements and test methods. ISO International Standard 10328: (2006).

DOI: 10.3403/30074527

[2] Z. Situm, T. Zilic and M. Essert. High Speed Solenoid Valves in Pneumatic Servo Applications. 15th Mediterranean Conference on Control & Automation, Athens, Greece, 2007 1-6.

DOI: 10.1109/med.2007.4433746

[3] Oscar Caldas, Sebastián Jiménez, Edilberto Mejía and Juan Hernández. Identificación paramétrica en lazo cerrado de sistema de accionamiento neumático para cilindro de doble efecto. Revista Facultad de Ingeniería, UPTC. 2012, 21 (33), 9-19.

[4] Atilio Morillo-Piña. Trayectory generation of differentially flat systems. Revista Técnica Ingeniería Universidad de Zulia. 2001, 24(1), 99-106.

[5] J. Linares-Flores, A. Antonio-García and A. Orantes-Molina. Arranque suave para un motor de CD a través de un convertidor reductor CD-CD. Ingeniería Investigación y Tecnología. 2011, 12(1), 137-148.

DOI: 10.22201/fi.25940732e.2011.12n2.014

[6] Hebertt Sira-Ramírez and Sunil Agrawal. Differentially Flat Systems. Control Engineering Series, Marcel Dekker, (2004).

[7] E. Chávez-Conde, F. Beltrán-Carbajal, A. Blanco-Ortega and H. Méndez-Azúa. Sliding Mode and Generalized PI Control of Vehicle Active Suspensions. 18th IEEE International Conference on Control Applications, Saint Petesburg, Rusia. 2009, 1726-1731.

DOI: 10.1109/cca.2009.5280947
