Design and Implementation of Mechatronic Prosthesis for Amputees with Trans-Humeral Amputation

Abstract:

The research project started with the need to found a viable solution to replace the upper extremities with artificial extremities, which have been affected by explosives such as land mines. For that purpose, it was essential the appliance of the design in the field of medicine for the construction of the anthropomorphic prosthesis. In order to do so, the concepts of biomechanics of the arm, including hand, as well as the types of handgrip was explored. According to the above, the concepts, moment, power, torque, four bar analysis were addressed, identifying the four bar mechanism and applying it on the design for the transmission of the movement in the phalanges..

• Periodical: Applied Mechanics and Materials (Volumes 713-715)
• Pages: 781-784
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.713-715.781
• Online since: January 2015
• Authors: Mauricio Mauledoux*, Juan C.M. Hernández, Oscar I. Caldas, Oscar F.S. Avilés, Hoffman F. Ramirez G.
• Keywords: Anthropomorphic, Biomechanics, GRIP, Gripper, Mechanic Hand, Prosthetics

References

[1] D. Robotics y M. C, Two-arm-system for investigation of two handed manipulation, (2013).

[2] D. Robotics y M. Center, Variable Stiffness Actuators (VSA) The Hand Arm System is equipped with 3 types of Variable Stiffness, (2013).

[3] N. Aeronautics y S. Administration, Robonaut 2, (2013).

[4] «Arm Prosthetic Device». (2010).

[5] D. research, The DEKA Arm, (2010).

[6] K. DESIGN, DARPA Revolutionizing Prosthetics 2009, (2010).

[7] ELUMOTION, Single digit featuring either 1 or 2 degrees of freedom, (2010).

[8] P. s. r. l, (2013).

[9] RLSSTEEPER, (2013).

[10] P. de Accion Integral contra Minas Antipersonal.

[11] D. Knudson, Fundamentals of Biomechanics, 2° ed., , Ed., Springer, 2007, pp.29-36.

[12] R. C. Miralles, Biomecánica clínica del aparato locomotor, M. S.A., Ed., Masson, (2000).

[13] J. Sánchez-Lacuesta, Biomecanica de la Marcha Humana Normal y Patologica, G. Valenciana, Ed., Instituto de Biomecanica de Barcelona, España, (1993).

[14] R. Drillis, R. Contini y M. Maurice Bluestein, Artificial Limbs, p.44, (1966).

[15] M. Nordin y V. Frankel, Biomecánica Básica del Sistema Musculoesquelético: Biomecánica de la muñeca y de la mano, McGraw Hill Interamericana, 2004, pp.370-398.

[16] M. Batmanabane y S. Malathi, «Movements at the carpometacarpal and metacarpophalangeal joints of the hand and their effect on the dimensions of the articular ends of the metacarpal bones, » The Anatomical Record, vol. 213, nº 1, pp.102-110, (1985).

DOI: 10.1002/ar.1092130114

[17] J. Shigley y J. Uicker, Teoría de Máquinas y Mecanismos, McGraw Hill, (1988).

[18] E. P. Flores, R. P. Quintero, O. A. Sánchez, P. N. Suárez y M. M. Vilchis, «Diseño del mecanismo actuador de un dedo robot antropomórfico, » Revista Facultad de Ingeniería Universidad de Antioquia, vol. 58, pp.153-162, (2011).

DOI: 10.18359/rcin.283
