Three Dimensional Model Construction and Strength Finite Element Analysis of Cold Shearing Machine Crankshaft

Abstract:

Cold shearing machine is the machine equipment often used in metallurgical industry to shear head, tail and fixed length of rolled piece. The shearing movement of cold shearing machine can be realized by crankshaft driving link rod with relative up-and-down motion. Load on crankshaft is comparatively big. In this paper, cold shearing machine crankshaft was taken as an example. The three dimensional model of relative cold shearing machine crankshaft was constructed by SolidWorks software. Strength finite element analyses on relative model were made by static analysis module attached to SolidWorks software under maximum load working conditions. The overall displacement distribution pictures and overall Von Mises stress distribution pictures of cold shearing machine crankshaft under relative load working conditions were obtained. This research provides important reference base for the design and reform of cold shearing machine crankshaft.

• Periodical: Applied Mechanics and Materials (Volumes 713-715)
• Pages: 95-98
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.713-715.95
• Online since: January 2015
• Authors: Ai Hua Li, Hong Yu Liu*
• Keywords: Cold Shearing Machine, Crankshaft, Strength Finite Element Analysis, Three Dimensional Model Construction

References

[1] Wankun Xing, Lai Yin. Calculation and Analysis of Compressor Crankshaft Strength Based on UG Environment [J]. Compressor Technology. 2014 52 (1) 6-8.

[2] Wei Luo, Huawei Zhang. The Strength Calculation and Fatigue Analysis of Diesel Engine Crankshaft Based on Finite Element [J]. Internal Combustion Engine ＆ Parts. 2014 35 (3) 36-38.

[3] Weicong Yan. Finite Element Analysis of Bridge Crane Girder Structure Based on SolidWorks [J]. Science & Technology of Ports. 2013 17 (7) 20-23.

[4] Dong Yang. The Finite Element Analysis on the Double Beam Bridge Crane Based on SolidWorks [J]. Sci-Tech Information Development ＆ Economy. 2009 19 (16) 177-179.
