Manufacturing Accuracy Control of Precision Machine Tool Based on Taguchi Method

Abstract:

In the manufacturing process of precision machine tool, the precision of the machine tool can not simply rely on parts design tolerance to achieve, and also need choose parts assemble for different tolerance values to ensure the accuracy of machine tools. Machine tool assembling deviation accumulation model is established by using the homogeneous coordinate transformation matrix, the quality loss function of taguchi methods apply to mechanical products matching activities. Considering the processing deviation of parts, the quality loss function of assembly cumulative deviation as an effective indicator for measure machine tool accuracy, the assembly precision of machine tools are ensured by optimize matching different geometric deviation parts. An example is given to testify the validity of this method.

• Periodical: Applied Mechanics and Materials (Volumes 716-717)
• Pages: 1545-1550
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.716-717.1545
• Online since: December 2014
• Authors: Chuan Lei Wang*, Qing Chao Sun, Xiao Kai Mu, Bo Wen Shi
• Keywords: Deviation Accumulation, Homogeneous Coordinate Transformation, Manufacturing Deviation, Precision, Taguchi Methods

References

[1] Hongjun, Junkang Guo, Zhigang Guo, Xiaopan Wu. Assembly accuracy prediction and adjustment process modeling of precision machine tool based on state space model [J]. Journal of Mechanical Engineering, 2002, 49(6): 114-121.

DOI: 10.3901/jme.2013.06.114

[2] JIN, SHI J. State space modeling of sheet metal assemble for dimensional control[J]. Journal of Manufacturing Science and Engineering, 1999, 121(7): 756-762.

DOI: 10.1115/1.2833137

[3] DING Y, CEGLAREK D, SHI J. Modeling and diagnosis of multistage manufacturing processes: Part I-sate space model [C]/Proceedings of the 2000 Japan/USA Symposium on Flexible Automation, July 23-26, Ann Arbor, MI, 2000jusfa-13146.

[4] MANTRIPRAGADA R, WHITNEY D E. Modeling and controlling variation state transition models [J]. IEEE Transactions on Robotics and Automation. 1999. 15(1) 124-140.

DOI: 10.1109/70.744608

[5] Xusong XU, Jiangxin Yang, Hanglong Cao, Maojian. Manufacturing error modeling based on homogeneous transformation [J]. Journal of Zhejiang University. 2008, 42(6): 1021-1026.

[6] COULLARD C R, GAMBLE A B, JONES P C. Matching problems in selective assembly operations[J]. Annals of Operations Research, 1988, 76: 95-107.

DOI: 10.1023/a:1018960924601

[7] Hangkong Cao, Jiangxin Yang, Zhaotong Wu, Liqun Wu. Robust tolerance design based on fuzzy quality loss [J]. Journal of Zhejiang University, 2004, 38(1)1-10.
