Doherty Power Amplifier with Dynamic Power Dividing Network for Enhanced Efficiency

Abstract:

In this paper, we present a high efficiency Doherty power amplifier (PA) employing dynamic power dividing network which automatically adjusts the input power division ratio in accordance with the level of input power to enhance efficiency. Doherty PA circuit parameters of each amplifier are determined by basic performance analysis according to the datasheet. Simulated circuits through Advanced Design System (ADS) exhibit an improvement of 4% at a 6 dB backoff point from its saturated output power (PSAT) than that of a conventional Doherty PA. Implemented Doherty PA using two Freescale MRF6S27015N laterally diffused metal oxide semiconductor (LDMOS) field-effect transistors (FETs) achieves excellent drain efficiency of 46.5% at a 6 dB backoff point from PSAT, which is 2% higher than conventional Doherty PA.

• Periodical: Applied Mechanics and Materials (Volume 721)
• Pages: 560-563
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.721.560
• Online since: December 2014
• Authors: Wang Xi*, Yu Shi, Shao Lin Yang, Jun Li
• Keywords: Doherty, Efficiency, LDMOS, Power Amplifier

References

[1] J. Kim, J. Moon and D. Kang, Doherty Power Amplifier Design employing Direct Input Power Dividing for Base Station Applications, Microwave Conference, European., Paris, 2010, pp.866-869.

[2] Takashi Yamamoto, Takaya Kitahara and Shigeru Hiura, 50% Drain Efficiency Doherty Amplifier with Optimized Power Range for W-CDMA Signal, Microwave Symposium, IEEE/MTT-S International., Honolulu, HI, 2007, pp.1263-1266.

DOI: 10.1109/mwsym.2007.380422

[3] Cheng-Zhi Fan, Xiao-Wei Zhu, Jing Xia and Lei Zhang, Efficiency Enhanced Class-F Doherty Power Amplifier at 3. 5GHz for LTE-Advanced Application, Microwave Conference Proceedings, Asia-Pacific., Seoul, 2013, pp.707-709.

DOI: 10.1109/apmc.2013.6694963

[4] Takaya Kitahara, Takashi Yamamoto and Shigeru Hiura, Doherty Power Amplifier with Asymmetrical Drain Voltages for Enhanced Efficiency at 8 dB Backed-off Output Power, Microwave Symposium Digest , IEEE MTT-S International., Baltimore, MD, 2011, pp.1-4.

DOI: 10.1109/mwsym.2011.5972945

[5] M. Nick, A. Mortazawi, Adaptive Input power Distribution in Doherty Power Amplifiers for Linearity and Efficiency Enhancement, IEEE Trans. Microwave. Theory Tech, Vol. 58 (2010) 2764-2771.

DOI: 10.1109/tmtt.2010.2077930
