The Design of the Minimum CPU System of TMS320VC54x

Abstract:

The minimum CPU system of TMS320VC54x DSP does not have redundant extended peripherals, it can work independently, perform real-time online simulation and burn program code. The paper mainly introduces the system design idea, the key points of design and matters needing attention, the paper offers the hardware circuit principle diagram of each unit of the minimum CPU system of TM320VC54x and the PCB diagram. The paper can work as the reference for the design of the minimum system of other CPU.

• Periodical: Applied Mechanics and Materials (Volume 721)
• Pages: 564-568
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.721.564
• Online since: December 2014
• Authors: Ai Ling Qu*, Chang Lu Ma, Bing Bing Qu
• Keywords: DSP, Minimum System, PCB, Principle Diagram, TMS320VC54x

References

[1] TMS320VC5402A Fixed-Point Digital Signal Processor, Texas Instruments, (2008).

[2] TMS320VC5416A Fixed-Point Digital Signal Processor, Texas Instruments, (2008).

[3] TMS320C54x DSP Reference Set: CPU and Peripherals, Texas Instruments, (2001).

[4] TMS320C54x DSP Reference Set: Enhanced Peripherals, Texas Instruments, (2007).

[5] TMS320C54x Assembly Language Tools User's Guide, Texas Instruments, (2001).

[6] TMS320C54x Optimizing C/C++ Compiler User's Guide, Texas Instruments, (2002).

[7] TMS320VC5402A/VC5409A/VC5410A/VC5416 Bootloader, Texas Instruments, (2006).
