The Analysis of the Static Mechanics for the Vehicle Frame

Abstract:

As an important part of the automobile assembly, automobile frame bears the complex loads from the road and loaded, and be installed car assembly as the carrier, and thus the frame strength and stiffness in the car overall played a very important role in the design. This article use Solid Works to design a frame of a truck, and focus on using the finite element analysis software ANSYS study mechanical analysis and study of the vehicle frame. Here discussed the pure bending conditions and reverse the conditions of static strength, the static stiffness analysis. The analysis showed that the frame of the stress value is less than the ultimate strength of materials to meet the design requirements, but the intensity is too large, so the economy is relatively poor, while considering the local strength of the frame. According to this characteristic of the truck frame, this paper presents a program on the frame lightweight design, the results of optimization makes the weight of frame to reduce, saving raw materials, lowering production costs, improving fuel economy .

• Periodical: Applied Mechanics and Materials (Volume 733)
• Pages: 505-508
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.733.505
• Online since: February 2015
• Authors: Wei Cheng Wu*
• Keywords: Bending, Finite Element, Static Analysis, Torsion, Vehicle Frame

References

[1] Feng G S. The Finite Element Analysis of Bus Body Structure [J]. Chinese Journal of Mechanical Engineering, 1999, 01, pp.128-129.

[2] Gui L J, Fan Z J, Chen Z Y. Study on Frame Rigidity of Minibus Changanzhixing [J]. Automobile Technology, 2003, 6, pp.28-32.

[3] Ma X, Sheng Y S. Finite element analysis and Optimization of frame stiffness and modal [J]. Automobile Technology, 2004, 4, pp.8-11.

[4] He Z G. Study on the Structure characteristics of Bus Body [D]. Jiangsu University, (2001).

[5] Li J Y. The Method of Finite Element [Z]. Beijing: Beijing University of Posts and Telecommunications Press, (1999).

[6] Li Z B. Analysis and Experimental Study Light Bus Structure [D]. Jiangsu University, (2003).

[7] Li X Y, Li C G, Hu Y J. General Conditions of the Frame Finite Element Analysis Technic [J]. Special Purpose Vehicle, 2001, 01, pp.13-17.

[8] Guan W. The Impact of Finite Element Analysis for its Performance of Truck Frame and Cars [J]. Automobile Technology, 2004, 20(4), pp.5-8.
