A Dedicated Device Based on the Spatial Electric Field for Measuring Voltage of Catenary System

Abstract:

The traditional high-voltage electroscope is difficult to distinguish normal catenary voltage and induced voltage. In order to solve the problem, a method to measure high-voltage based on the effect of space electric field is proposed and a dedicated catenary voltage measuring device is made. The method follows divider effect of spatial capacitance and achieves quantitative voltage measurement without grounding by measuring and transforming the induced voltage difference of the capacitance which is placed between the catenary system and the earth and showing the actual catenary voltage value in LCD. The device can effectively distinguish catenary normal voltage and induced voltage, then reflects catenary real operation state. The field test results show the device meets the requirement of catenary voltage measurement.

• Periodical: Applied Mechanics and Materials (Volume 734)
• Pages: 109-112
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.734.109
• Online since: February 2015
• Authors: Jia Song*, Xiao Dong Zhang, Yue Jia Sun
• Keywords: Catenary System, Effect of Space Electric Field, Quantitative, Voltage Measurement

References

[1] Yongle Yan, Study of Contact Wire Grounding of Power Cut Construction in Electrified Railway, Railway Signaling & Communication, vol. 4, pp.30-31, (2009).

[2] Ministry of Railways of the PRC, The catenary safety procedures, China Railway Publishing House, Beijing, China, (2007).

[3] Bin Wang and QuanXiao Wang, Research on Induction Voltage of Traction Electric Network of High-speed Railway, Journal of Railway Engineering Society, vol. 3, pp.77-80, (2011).

[4] Xiaoqiong Pei and Yuxin Yan, Influence of faradism Induced Voltage on Starting Voltage of High-voltage Electroscope, Railway Locomotive & Car, vol. 1, no. 26, pp.69-70, (2006).

[5] Lei Ma and Jiakun Bai, Explore the 27. 5kV Capacitive Pressure Electroscope examine the electrical dead catenary reason, Electric Railway, vol. 4, pp.14-15, (2013).

[6] Wenqiang Liao, Analysis of Capacitance Electroscope with Defects and its Countermeasures, Telecom Power Technologies, vol. 2, pp.79-80, (2013).

[7] Peijun Wang, Ping Zhang and Liyong Wang, Problems and Countermeasures of Capacitance Electroscope in use, Electric Safety Technology, vol. 8, pp.54-55, (2006).

[8] Ningping Tang, Shaoyu Rou and Fuwang Liao, Research on high-voltage test equipment based on effect of space electric field, Advanced Technology of Electrical Engineering and Energy, vol. 1, no. 28, pp.25-28, (2009).
