Theoretical Investigation in an Artificial Hip Joint under Elastohydrodynamic Lubrication

Abstract:

This paper describes the transient analysis of artificial hip joint during human movement under elastohydrodynamic lubrication (EHL) with non-Newtonian lubricants based on a Carreau model. During walking, the load and velocity are varying with time. The numerical schemes employed perturbation method, Newton-Raphson method and multi-grid multilevel with full approximation technique to solve the time-dependent modified Reynolds equation and elasticity equation with initial conditions. The aim of this study was investigated the characteristics of elastohydrodynamic lubrication, profile of film pressure and film thickness profile in human artificial hip joint during human movement. Numerical results show the transient film thicknessincreased and then decreased because of reverse motion. In smooth surface condition, film thickness for Newtonian fluids is slightly higher than the film thickness for non-Newtonian fluid. The amplitude of surface roughness has significant effect on the film thickness,the minimum film thickness decreased when the amplitude of surface roughness increases.

• Periodical: Applied Mechanics and Materials (Volume 736)
• Pages: 140-145
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.736.140
• Online since: March 2015
• Authors: Khanittha Wongseedakaew*
• Keywords: Artificial Hip Joint, Mutigrid Method, Transient EHL, Walking Condition

References

[1] DowsonD. andHigginsonG.R.: Elastohydrodynamic Lubrication: The Fundamental of Roller and Gear Lubrication, Pergamon, Oxford, (1966).

[2] MurakamiT., HigakiH., SawaeY., OhtsukiN., MoriyamaS. and Nakanishi Y. Adaptive multimode lubrication in natural synovial joints and artificial joints: JSME Int. Journal Series III (1990); p.334: 456-474.

[3] MongkolwongrojnM., WongseedakaewK. and KennedyF.E., Transient elastohydrodynamic lubrication in artificial knee joint with non-Newtonian fluids, Tribology International, (2010), Vol. 43, p.1017–26.

DOI: 10.1016/j.triboint.2009.12.041

[4] KennedyF.E., WongseedakaewK., McHugh D. J. and CurrierJ.H., Tribological conditions in mobile bearing total knee prostheses, Tribology International, (2013), Vol. 63, pp.78-88.

DOI: 10.1016/j.triboint.2012.03.011

[5] WongseedakaewK., Transient Thermo-Elastohydrodynamic Lubrication of Rough Surface in Soft Material, Advanced Materials Research, (2013), Vol. 651, pp.505-510.

DOI: 10.4028/www.scientific.net/amr.651.505

[6] LubrechtA.A., NapelW.E. ten and BosmaR., Multigrid an Alternative method for calculating film thickness and pressure profiles in elastohydrodynamically Lubricated Line Contacts, ASME Journal of Tribology, (1986), Vol. 108, pp.551-556.

DOI: 10.1115/1.3261260

[7] Osborn F.K. andSadeghiF., Time Dependent Line EHD Lubrication Using the Multigrid/Multi-level Technique, ASME J. Tribol., (1992), Vol. 114, p.68–74.

DOI: 10.1115/1.2920870

[8] RoelandsC.J.A., Correlational Aspects of the Viscosity-Temperature-Pressure Relationship of Lubricating Oils, Druk, V.R.B., Groingen, Netherland, (1969).

[9] Dowson D. and JinZ.M., Metal on Metal Hip Joint Tribology, Proc. IMechE Part H: Journal of Engineering in Medicine, (2006), Vol. 220, pp.107-118.

DOI: 10.1243/095441105x69114
