Fiber Bragg Grating Hydrogen Sensor Applied for Partial Discharge Detection in Transformer Oil

Abstract:

Most optical hydrogen sensors are based on light intensity measurement and light intensity detection is vulnerable to the light source output and the optical fiber arrangement. To overcome the shortcomings, an optical fiber based sensor based on fiber Bragg grating (FBG) technique which is capable to measure the concentration of hydrogen dissolved is described in this paper. To examine the availability of monitoring initial hydrogen generation, a needle-to-plate partial discharge (PD) model was setup in the lab. The results between wavelength shifts of optical hydrogen sensor well agreed with conventional dissolved gas analysis (DGA), proving a potential utilization in the detection of dissolved hydrogen in power transformer.

• Periodical: Applied Mechanics and Materials (Volumes 738-739)
• Pages: 11-14
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.738-739.11
• Online since: March 2015
• Authors: Ying Ting Luo*, Hong Bin Wang, Wen Jun Zhu, Zhen Wu, Hong Tu Song, Xiong Li
• Keywords: Detection Sensor, Dissolved Hydrogen, FBG, Partial Discharge (PD), Transformer Oil

References

[1] Thang K F, Aggarwal R K and McGrail A J: IEEE T. Power Deliver., Vol. 18 (2003), pp.1241-1248.

[2] Ward B H: IEEE Electr. Insul. M., Vol. 17 (2001), pp.16-23.

[3] Singh S and Bandyopadhyay M N: IEEE Electr. Insul. M., Vol. 26 (2010), pp.41-46.

[4] Judd M D, Yang L and Hunter I B: IEEE Electr. Insul. M., Vol. 26 (2005), pp.5-14.

[5] Buric M, Chen T and Maklad M: IEEE Photonic. Tech. L., Vol. 21 (2009), pp.1594-1596.

[6] Schroeder K, Ecke W and Willsch R: Opt. Laser. Eng., Vol. 47 (2009), pp.1018-1022.

[7] Caucheteur C, Debliquy M and Lahem D: IEEE Photonic. Tech. L., Vol. 20 (2008), pp.96-98.
