Design of Universal Interface Used in Function Modules of Remote Medical Monitoring Equipment

Abstract:

In this article,an universal interface used in function modules of remote medical monitoring equipment is introduced.This interface was a versatile interface which can be used in the connections between all kinds of function modules and host of a remote medical monitoring equipment.Implementation of this universal interface not only improved the flexibility of monitoring equipment but also reduced the complexity of the design processes.This interface supported the hot-swap technology and hence provided easy-using,an uninterrupted monitoring during troubleshooting process and reduced maintenance time.This article introduced the design of this interface which was flexible and universal in three aspects,including its physical structure,circuit and software design.

• Periodical: Applied Mechanics and Materials (Volumes 738-739)
• Pages: 1285-1288
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.738-739.1285
• Online since: March 2015
• Authors: Dan Fei Huang, Jun Qiang Chen, Guan Hai Peng
• Keywords: Interface Design, Interface Pin, Interface Software Design

References

[1] Hu Zongtai. Trend several categories of medical devices[J]Chinese Medical Device Information, 2009, 5 (3): 38-42.

[2] Yang Qian, MingXia He. The latest progress of medical monitors technology[J]Medical Equipment, 2006, 27(8): 38-39.

[3] Fei Song, Hushi Ping, Yaoxi Nan. LT1641 dual hot-swap circuit design[J]. Applications based on electronic components, 2008, 10(4): 4-7.

[4] Niyao De, Xiezheng Xiang. Biomedical digital signal processing technology and application[M]Beijing: Science Press, (2005).

[5] Yeyao Bi, Feng Li, Ye Zhen. Based protection circuit MAX4271 hot-swap[J] electron mass, 2003, (3): 20-21.

[6] Yan li Zhao, Zhi meng Liu. Video monitoring system hardware design based DSP[J]. Microcontroller and Embedded Systems. 2007, 5: 39-41.
