Study on the Steady-State Stability Margin of a Weak Section by Using the Online Data of WAMS

Abstract:

To realize the on-line quick analysis of the steady-state stability margin for the weak section of a power grid, a method of dividing the important generator groups according to the impact of the system equivalent impedance on the static stability limits of the section is presented. By using the dynamic information provided by the Wide Area Measurement System (WAMS), the center of inertia (COI) of the section of the two sides system is determined. Then the steady-state stability limits of the transmission section and the static stability margin can be calculated. The algorithm is verified by taking the out-play cross-section of West Inner Mongolia as an example, the results show that the static stability power limit and the steady-state stability margin of the section can be obtained accurately according to the presented algorithm. This algorithm can provide an effective analytical method for the online static stability security analysis of a power system.

• Periodical: Applied Mechanics and Materials (Volumes 738-739)
• Pages: 1289-1295
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.738-739.1289
• Online since: March 2015
• Authors: Wen Chao Zhang, Xin Qiao Fan, Yu Long He, Yan Pan, Yong Lu
• Keywords: Center of Inertia, Steady-State Stability Margin, WAMS

References

[1] Daowei Liu, Xueshan Han, Yong Wang, et al. Studies on the on-line static stability region in power systems and its application [J]. Proceedings of CSEE, 2009, 29(34): 42-50.

[2] Zhenxiang Han, Yijia Cao. Power system security and its prevention[J]. Power System Technology, 2004, 28(9): 1-6.

[3] XiaoXin Zhou, Qiang Lu, et al. Chinese Dictionary of Electrical Engineering, VIII Power Systems Engineering [M]. Beijing: China Electric Power Press, 2008: 64-70.

[4] Jianfeng Yan, Zhihong Yu, Fang Tian, et al. Dynamic security assessment and early warning system of power system[J]. Proceedings of the CSEE, 2008, 28(34): 87-93.

[5] Jinquan Zhao, Xiaodong Jiang, Boming Zhang. An on-line enhancement control algorithm for static stability power system[J]. Proceedings of the CSEE, 2005, 25(8): 7-12.

[6] Wei Pan, Wenying Liu, Yihan Yang. Method of identifying coherent generator groups by independent component analysis through perturbed trajectories[J]. Proceedings of CSEE, 2008, 28(25): 86-92.

[7] Jonsson M, Begovic M, Daalder J. A new method suitable for real-time generator coherency determination[J]. IEEE Trans on Power Systems, 2004, 21(3): 1473-1482.

DOI: 10.1109/tpwrs.2004.826799

[8] Q/GDW 404—2010 The provisions of the security and stability of power system [S]. Beijing: China Electric Power Press, (2010).

[9] Zuping Zhang, Jun Yang, Zhaoxu Liu, et al. Research on static stability limit of Fujian and East China power line networking computing[C]/Proceedings of the National Power System Technology Conference . Xiamen: CSEE, 2001: 179-185.

[10] Zhou Lan, Haojun Zhu, Deqiang Gan, et al. A study on control of AC/DC power systems based on COI information[J]. Power System Technology, 2007, 31(6): 14-18.

[11] Yang Liu, Linchuan Li. A method of calculating maximum transmission capability of tie line considering transient stability constraints [J]. Power System Technology, 2006, 30(11): 56-61.

[12] Wenchao Zhang, Yulong He, Xueping Gu. et al. A fast method to estimate steady-state stability limit of tie line in single power transmission channel[J]. Power System Technology, 2012, 5(36): 92-95.
