Distributed Capacitance Calculation Model in GIS Voltage Transformer’s Error Test

Abstract:

With the advantages of miniaturization and high reliability, Gas Insulated Substations (GIS) have been applied to power systems widely. However, GIS voltage transformers have troubles in boosting voltage in error test because of GIS’s special physical structure. A calculation model was proposed to solve the difficulty of distributed capacitances’ calculation when it adopts series resonance method in error test. By analyzing and getting the corresponding parameters of primary equipment, a GIS voltage transformer’s test connection equivalent model was built. Compared with measured value in a 500 kV GIS hydropower station, the error is below 8%. And the results confirmed that the long-distance bus and metal shell will form a large distributed capacitances which have a great impact on the error test. In this paper, the calculation model provides theoretical basis for error test. Moreover, it can be applied to field test, which will save equipment transportation costs, time and resources.

• Periodical: Applied Mechanics and Materials (Volumes 738-739)
• Pages: 820-825
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.738-739.820
• Online since: March 2015
• Authors: Xian Shun Chen*, Yong Sen Li, Yang Jiao, Guo Ci Lei
• Keywords: Distributed Capacitance, Error Test, GIS Voltage Transformer, Resonance Step-Up

References

[1] Yu-shu Chen, Yong-chao Pan, Yuan Zhao, et al. Research on field verification technology of substation intelligent measurement system [J]. Electrical Measurement & Instrumentation, 2013, (05): 77-80.

[2] Jia-heng Xu, Xiao-wu Qu, Lei Zhen, et al. Discussion on the error test method of transformer in 126kV GIS [J]. High Voltage Apparatus, 2003, (02): 56-58.

[3] Aristoy G., Santos A., Slomovitz D. Effects of stray capacitances on high voltage current transformers[C]. Instrumentation and Measurement Technology Conference (I2MTC) Proceedings, 2014 IEEE International, 2014: 348-351.

DOI: 10.1109/i2mtc.2014.6860765

[4] Tziouvaras D A．Mathematical models for current, voltage, and coupling capacitor voltage transformer [J]. IEEE Trans on Power Delivery，2000，15 (1) ：62-70.

[5] Zhen-dong Li, Nan Jia, Rong-hui Hu. Discussion of PT error test method in GIS [J]. Qinghai Electric Power, 2011, (03): 12-13.

[6] Yu-fu Zhao, Zhuo-ya Chen, Xiao-ran Gu. On-site calibration for TV of GIS [J]. Electrical Measurement & Instrumentation, 2007, (08): 34-36.

[7] Chuan-xian Luo, Zhao-yang Xu, Hong-tao Shen, et al. The error test of on-site 500kV voltage transformer [J]. Electrical Measurement & Instrumentation, 2004, (12): 21-24.

[8] Yong-hui Wang, Jian-po Geng, Jian-zhong Yin, et al. Sites error survey of 550kV voltage transformer in GIS [J]. Hebei Electric Power, 2008, (03): 3-5.

[9] Wei-bo Li, Cheng-xiong Mao, Ji-ming Lu, et al. Study of the Influence of the Distributed Capacitance on Dynamic Property of Rogowski Coil [J]. Transactions of China Electrotechnical Society, 2004, 19(6): 12-17.
