The Tape Measurement System Based on Computer Vision Technology

Abstract:

The paper devises a computer vision system based on virtual instruments to measure tape. The dark field illumination is chosen as Lampe-house in this system. Use Image processing technologies of Median filter, Image binarization, Template matching, Edge extraction to extract a reticle of tape. And compare it with standard tape enacted in this system to measure reticle error of the tape. Analyze various factors influencing the detection precision of the system. Tests show that the measurement results of this system are accurate, reliable and practicable.

• Periodical: Applied Mechanics and Materials (Volumes 738-739)
• Pages: 816-819
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.738-739.816
• Online since: March 2015
• Authors: Hong Zhou Li, Jie Lu, Jun Wang, Tao Jia
• Keywords: Dark Field Illumination, Error, LabVIEW, Tape, Vision Technology

References

[1] Aiwen Peng, Lianmin Xie. Calibration of steel tape with EOD Instrument. Bulletin of surveying and mapping, VOL. 3(2000), P38.

[2] Xiangjun Yuan. solid image sensor and it are applied. Chongqing university press, (1992).

[3] Bo Su, Jilong Wang, Yuncai Wang. The research of linear array ccd driving circuit. The journal of shanxi teachers university, VOL. 1(2002), p.41.

[4] Weixian Jin, Xianhong Yang. Photogrammetry. Wuhan technical university of surveying and mapping, 1996.

[5] Qingyou Wang . CCD applied technology. Tianjin university press, 2000, 10.
