The Control System for Three-Phase Induction Motors Based on Stator Flux Orientation

Abstract:

In this paper, the mathematical model of induction motor based on stator field orientation in synchronous frame is introduced. To resolve the question of relay, the d-axis current direct calculation is adopted to replace traditional decoupler. Fix threshold double-integrator based on coordinate transformation is used to eliminate integrator saturation. SVPWM based on 60⁰ coordinate system is developed to simplify calculation. The control system based on stator flux orientation is simulated by MATLAB. The simulation result shows that the system has a fast dynamic response and steady characteristics.Nomenclature

• Periodical: Applied Mechanics and Materials (Volume 740)
• Pages: 355-358
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.740.355
• Online since: March 2015
• Authors: Feng Long Shen*
• Keywords: Decoupling, Flux Observer, Stator Flux Orientation, Three-Phase Induction Motors

References

[1] Boshi Chen, in: Electric drive automatic control system, Beijing (2007), Machine press. In Chinese.

[2] Ni Qiang, Xiaoyun Feng, Xinrao Hou, Yongheng Liao: Research on Control Method of Asynchronous Motor Based on the Stator Flux -oriented. Power Electronics Motor 45(2011), pp.55-57. In Chinese.

[3] Yongkui Man, Xuehai Chen: The Space Vector Control for Induction Motors Based on Stator Flux Orientation. The 6th IEEE Conference, Industrial Electronics and Application, 2011, pp.1265-1268.

DOI: 10.1109/iciea.2011.5975780

[4] Fenglong Shen, Yongkui Man, Jianhui Wang, Chuanyuan Bian: Control Method Based on Non-orthogonal Coordinate Frame for NPC Three-level Inverter. Electric Drive, Vol. 42(2012), pp.50-53. In Chinese.

DOI: 10.1109/ccdc.2012.6244400

[5] Fenglong Shen, Yongkui Man, Jianhui Wang, Chuanyuan Bian: Design and Experimental Study of regulator of Vector Control System. Electric Drive, Vol. 43(2013), pp.3-6. In Chinese.

[6] Yonghong Du, Zhefeng Li, Zhigang Liu: Indirect Field Orientation Double Close Loop System of Induction Motor. Transactions of China Electrotechnical Society, Vol. 24(2009), pp.24-28. In Chinese.
